2931683 Festo Pinch Valves
Part#:2931683
Alt. Part#:VZQA-C-M22U-6-GG-V4V4S1-4
Manufacturer:Festo
Category:Pinch Valves
Product Lifecycle:Active
Product description
Pinch valve VZQA-C-M22U-6-GG-V4V4S1-4 Pneumatically actuated pinch valve in stainless steel, safety position open, G thread, DN6, food materials and articles. Design structure: Pneumatically actuated pinch valve, Type of actuation: pneumatic, Sealing prin
Product Details
- Type code VZQA
- Sealing principle Soft
- Valve function 2/2, open, monostable
- Type of mounting Line installation
- Nominal width DN 6
- Medium Compressed air as per ISO 8573-1:2010 [-:-:-]
- On switching time 125 ms
- Housing cover material High-alloy stainless steel
- Housing material High-alloy stainless steel
- Differential pressure 2.5 bar
- Actuation type Pneumatic
- Fitting connection G1/4
- Flow direction Reversible
- Auxiliary pilot air port 12 M5
- Max. viscosity 4000 mm²/s
- Storage temperature 5 °C ... 30 °C
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Shut-off element material VMQ (silicone)
- Material of bowl PA6
- Burst pressure 16 bar
- Overload pressure 7.8 bar
- Mounting position Any
- Type of control Externally controlled
- Pilot medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Ambient temperature -5 °C ... 60 °C
- Product weight 157 g
- Operating pressure 1 bar ... 6.5 bar
- Medium pressure 0 bar ... 4 bar
- Design Pinch valve, pneumatically operated
- Reset method Rebound resilience
- Symbol 00995245
- Switching time off 125 ms
- For use in the food industry See declaration of conformity
- Nominal pressure of fitting PN 10
- Temperature of medium -5 °C ... 150 °C
- Flow rate Kv 0.7 m³/h
- Material number of housing 1.4404
- Seals material FPM
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
