2376018 Festo Cable Assemblies

Product Details

• Based on norm
  DIN 47100
• Contact durability
  50
• Type code
  NEBC
• Electrical connection 1, connection type
  Socket
• Electrical connection 2, connection type
  Cable
• Cable characteristic
  Standard
• Note on degree of protection
  In mounted state
• Color cable sheath
  Gray
• Housing colour
  Gray
• Electrical connection 1, design
  Rectangular
• Electrical connection for input 1, connection pattern
  00995638
• Current rating at 40°C
  5.2 A
• Cable diameter tolerance
  ± 0.1 mm
• Special features
  Easy to clean
• Material of cable sheath
  PVC
• Seals material
  EPDM
• Product weight
  300 g
• Electrical connection 1, connection technology
  Sub-D
• Electrical connection 1, number of pins/wires
  9
• Electrical connection 2, number of pins/wires
  5
Cable length
2.5 m
Bending radius, flexible cable installation
≥ 78 mm
Nominal conductor cross section
0.5 mm²
Ambient temperature with flexible cable installation
-5 °C ... 60 °C
Contamination level
3
Housing material
PA-reinforced
Protocol
I-Port
Cable designation
Without label holder
Electrical connection 1, function
Field device end
Electrical connection 1, occupied pins/wires
5
Electrical connection 2, function
Control side
DC operating voltage range
0 V ... 30 V
Cable diameter
6.5 mm
Degree of protection
IP65 IP69K
Storage temperature
-20 °C ... 40 °C
Ambient temperature
-5 °C ... 60 °C
Material of screws
Stainless steel
Insulating sheath material
PVC
Electrical connection 1, cable outlet
Angled
Electrical connection 1, type of mounting
2x screw, 4-40 UNC With seal
Electrical connection 2, connection technology
Open end
Protective earth connection
Not available
Bending radius, fixed cable installation
≥ 26 mm
Cable design
5 x 0.5 mm²
Note on materials
RoHS-compliant
Corrosion resistance class (CRC)
3 - High corrosion stress
Material of pin contacts
Bronze, gold-plated
