2078 Festo Pneumatic Components

2078 on Powermatic Associates
Festo

Part#:2078

Alt. Part#:FR-8-1/4

Manufacturer:Festo

Category:Pneumatic Components

Product Lifecycle:Active

Product description

distributor block FR-8-1/4 For distribution of compressed air. Nominal size: 11,5 mm, Assembly position: Any, Operating pressure complete temperature range: 0 - 16 bar, Operating medium: Compressed air in accordance with ISO8573-1:2010 [7:-:-], Note on op

Product Details

  • Operating pressure for entire temperature range
    0 bar ... 16 bar
  • Type code
    FR
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • No. of supply lines
    1
  • Nominal tightening torque
    14 Nm
  • Mounting position
    Any
  • No. of outlets
    8
  • Ambient temperature
    -10 °C ... 60 °C
  • Pneumatic connection 2
    Internal thread G1/4
  • Pneumatic connection 1
    Internal thread G1/2
  • Nominal width
    11.5 mm
  • Tolerance for nominal tightening torque
    ± 20%
  • Corrosion resistance class (CRC)
    0 - No corrosion stress
  • Note on materials
    RoHS-compliant
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Product weight
    230 g
  • Housing material
    Die-cast aluminum

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
