195101 Festo Compressed Air Preparation Units

195101 on Powermatic Associates
Festo

Part#:195101

Alt. Part#:LFRS-3/4-D-MAXI-KE-A

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

Product description

service unit LFRS-3/4-D-MAXI-KE-A With lockable regulator head and pressure gauge, for nominal pressure 12 bar, for unlubricated compressed air. Size: Maxi, Series: D, Actuator lock: Rotary knob with integrated lock, Assembly position: Vertical +/- 5°, Gr

Product Details

  • Condensate drain
    Fully automatic
  • Pressure gauge
    with pressure gauge
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Type of mounting
    Optionally: With accessories
  • Pneumatic connection 2
    G3/4
  • Symbol
    00991778
  • Operating pressure
    2 bar ... 12 bar
  • Standard nominal flow rate
    9400 l/min
  • Ambient temperature
    -10 °C ... 60 °C
  • Material of bowl
    PC
  • Series
    D
  • Grade of filtration
    40 µm
  • Design
    Branching module Filter regulator with pressure gauge
  • Air quality class at the output
    Compressed air as per ISO 8573-1:2010 [7:8:4] Inert gas
  • Pneumatic connection 1
    G3/4
  • Type code
    LFRS
  • Mounting position
    Vertical +/- 5°
  • Max. condensate volume
    80 ml
  • Pressure regulation range
    0.5 bar ... 12 bar
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [-:-:-] Inert gas
  • Product weight
    2500 g
  • Housing material
    Die-cast zinc
  • Size
    Maxi
  • Actuator lock
    Rotary knob with integrated lock
  • Bowl guard
    Metal bowl guard
  • Max. pressure hysteresis
    0.3 bar
  • Temperature of medium
    -10 °C ... 60 °C

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

195101 Related Documents

195101 DataSheet.pdf
