192734 Festo Pressure Gauges

Name: 192734
Brand: Festo

Part#:192734

Alt. Part#:MA-50-1-G1/4-MPA

Manufacturer:Festo

Category:Pressure Gauges

Product Lifecycle:Active

Product description

pressure gauge MA-50-1-G1/4-MPA With display unit in MPa. Indicating range [MPa]: 0 - 1 MPa, Conforms to standard: EN 837-1, Nominal size of pressure gauge: 50, Design structure: Bourdon-tube pressure gauge, Mounting type: Line installation

Product Details

Explosion prevention and protection
Observe the information on the certificate Zone 22 (ATEX)
Measurement accuracy class
2.5
Connection position
Centered on rear side
Product weight
70 g
Type code
MA
Design
Bourdon tube pressure gauge
Type of mounting
Line installation
Note on materials
RoHS-compliant
Housing colour
Black
Display range
0 MPa ... 1 MPa
Pressure gauge nominal size
50
Intermittent load factor
0.66
Temperature of medium
-20 °C ... 60 °C
Pneumatic connection
G1/4
Housing material
ABS
Inspection window material
PS
Symbol
00991463
Operating medium
Inert gas Neutral liquids
Degree of protection
IP43
Material of screwed trunnion
Brass

Conforms to standard

EN 837-1

Operating pressure

0 bar ... 10 bar

Ambient temperature

-20 °C ... 60 °C

Materials in contact with the media

Brass

Information on operating and pilot media

No acetylene No oxygen

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
