191078 Festo Vacuum Cups

191078 on Powermatic Associates
Festo

Part#:191078

Alt. Part#:ESV-50-CS

Manufacturer:Festo

Category:Vacuum Cups

Product Lifecycle:Active

Product description

vacuum suction cup ESV-50-CS Wearing part, easily replaceable Suction cup height compensator: 17,5 mm, Min. workpiece radius: 180 mm, suction cup diameter: 50 mm, suction cup volume: 38,92 cm3, Position of connection: on top

Product Details

  • Min. workpiece radius
    180 mm
  • Symbol
    00991485
  • Suction cup shape
    Round bellows, 3.5 convolutions
  • Connection position
    Top
  • Ambient temperature
    -30 °C ... 180 °C
  • Color
    Transparent
  • Suction cup diameter
    50 mm
  • Mounting position
    Any
  • Holding force at nominal operating pressure
    63.4 N
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Suction cup height compensation
    17.5 mm
  • Type code
    ESV
  • For use in the food industry
    See supplementary material information
  • Shore hardness
    50 +/- 5
  • Suction cup volume
    38.92 cm³
  • Operating medium
    Atmospheric air based on ISO 8573-1:2010 [7:-:-]
  • Product weight
    21.3 g
  • Suction cup material
    VMQ (silicone)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
