189278 Festo Vacuum Cups

189278 on Powermatic Associates
Festo

Part#:189278

Alt. Part#:ESS-6-SNA

Manufacturer:Festo

Category:Vacuum Cups

Product Lifecycle:Active

Product description

suction cup ESS-6-SNA Wearing part, easily replaceable Min. workpiece radius: 15 mm, Nominal size: 2 mm, suction cup diameter: 6 mm, suction cup volume: 0,015 cm3, Ejector pulse suitability: <: 4 bar

Product Details

  • Color
    Black/white dot
  • Suction cup volume
    0.015 cm³
  • Symbol
    00991485
  • Operating medium
    Atmospheric air based on ISO 8573-1:2010 [7:-:-]
  • Lateral force at nominal operating pressure
    2 N
  • Mounting position
    Any
  • Operating pressure
    0 bar ... 0.95 bar
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Suction cup material
    BR
  • Suction cup diameter
    6 mm
  • Ejector pulse suitability
    ≤ 4 bar
  • Classification of suction cup holder
    Size 2
  • Nominal operating pressure
    -0.7 bar
  • Holding force at nominal operating pressure
    1.1 N
  • Vacuum connection
    Inside diameter 4 mm
  • Shore hardness
    50 +/- 5
  • Min. workpiece radius
    15 mm
  • Type code
    ESS
  • Suction cup shape
    Round, flat
  • For use in the food industry
    See supplementary material information
  • Product weight
    0.2 g
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Nominal width
    2 mm
  • Connection position
    Top
  • Special features
    Anti-static
  • Ambient temperature
    -10 °C ... 70 °C
  • Type of mounting
    Via vacuum connection
  • Material of screwed trunnion
    Brass, nickel-plated

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
