187762 Festo Proportional Valves

Product Details

• KC characters
  KC EMC
• Actuation type
  Electrical
• Symbol
  00995305
• Valve function
  3-way proportional pressure control valve closed
• Switching time off
  410 ms
• Residual ripple
  10 %
• Exhaust nominal width
  2 mm
• Short-circuit protection
  For all electrical connections
• Max. pressure hysteresis
  0.01 bar
• Information on operating and pilot media
  Operation with oil lubrication possible (required for further use)
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Electrical connection
  8-pin Round design
• Housing material
  Wrought aluminum alloy
• Type code
  MPPES
• Safety instructions
  MPPES safety position: if the power supply cable breaks, the outlet pressure will drop to 0 bar.
• Pressure regulation range
  0 bar ... 10 bar
• Inlet pressure 1
  11 bar ... 12 bar
• CE marking (see declaration of conformity)
  As per EU EMC directive
• Certification
  RCM compliance mark
• Pneumatic connection 1
  G1/8
Diaphragm material
NBR
Nominal width pressurization
3 mm
Design
Directly controlled piston regulator
Reverse polarity protection
for all electrical connections
DC operating voltage range
18 V ... 30 V
Temperature of medium
0 °C ... 60 °C
Note on materials
RoHS-compliant
Sealing principle
Soft
Mounting position
Any
Operating pressure
≤ 12 bar
On switching time
220 ms
Setpoint/actual values
Current type 4–20 mA
Ambient temperature
0 °C ... 50 °C
Pneumatic connection 3
G1/8
Type of mounting
With through-hole
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
Degree of protection
IP65
Product weight
915 g
Pneumatic connection 2
G1/8
