18625 Festo Cable Assemblies

18625 on Powermatic Associates
Festo

Part#:18625

Alt. Part#:KMP3-25P-16-10

Manufacturer:Festo

Category:Cable Assemblies

Product Lifecycle:Active

Product description

connecting cable KMP3-25P-16-10 For valve terminal CPV. Based on the standard: DIN 41652, Cable identification: with accessories, Connection frequency: 50, Product weight: 1303 g, Electrical connection 1, function: Field device side

Product Details

  • Electrical connection 1, connection technology
    Sub-D
  • Electrical connection 1, number of pins/wires
    25
  • Surge resistance
    1 kV
  • Cable designation
    With accessories
  • Product weight
    1303 g
  • Electrical connection 1, occupied pins/wires
    18
  • Electrical connection 2, connection type
    Cable
  • DC operating voltage range
    0 V ... 30 V
  • Cable characteristic
    Standard
  • Bending radius, fixed cable installation
    ≥ 45 mm
  • Nominal conductor cross section
    0.34 mm²
  • Ambient temperature with flexible cable installation
    -5 °C ... 70 °C
  • Housing material
    PA
  • Seals material
    NBR
  • Contact durability
    50
  • Electrical connection 1, connection type
    Socket
  • Electrical connection 1, type of mounting
    2x M3 screw
  • Electrical connection 2, number of pins/wires
    18
  • Nominal operating voltage DC
    24 V
  • Cable diameter
    8.5 mm
  • Degree of protection
    IP65
  • Storage temperature
    -25 °C ... 75 °C
  • Material of pin contacts
    Copper alloy, gold-plated
  • Type code
    KMP3
  • Electrical connection 1, function
    Field device end
  • Electrical connection for input 1, connection pattern
    00995642
  • Electrical connection 2, function
    Control side
  • Electrical connection 2, occupied pins/wires
    18
  • Cable length
    10 m
  • Cable design
    18 x 0.34 mm²
  • Note on degree of protection
    In mounted state
  • Ambient temperature
    -25 °C ... 70 °C
  • Contamination level
    3
  • Based on norm
    DIN 41652
  • Electrical connection 1, design
    Rectangular
  • Electrical connection 1, cable outlet
    Angled
  • Electrical connection 2, connection technology
    Open end
  • Current rating at 40°C
    3 A
  • Connector cable test conditions
    Test conditions on request
  • Cable diameter tolerance
    ± 0.5 mm
  • Material of cable sheath
    PVC
  • Bending radius, flexible cable installation
    ≥ 90 mm
  • Wire ends
    Cut off bluntly
  • Note on materials
    RoHS-compliant
  • Color cable sheath
    Gray

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
