178414 Festo Pneumatic Tubing

178414 on Powermatic Associates
Festo

Part#:178414

Alt. Part#:PUN-12X2-RT

Manufacturer:Festo

Category:Pneumatic Tubing

Product Lifecycle:Active

Product description

plastic tubing PUN-12X2-RT Standard O.D tubing, for QS plug connectors, CN and CK polyurethane fittings (not approved for use in the food industry). Outside diameter: 12 mm, Bending radius relevant for flow rate: 62 mm, Inside diameter: 8 mm, Min. bending

Product Details

  • Outside diameter
    12 mm
  • Type code
    PUN
  • Temperature-dependent operating pressure
    -0.95 bar ... 10 bar
  • Shore hardness
    D 52 +/-3
  • Bending radius relevant for flow rate
    62 mm
  • Certificate issuing authority
    B 013277 0506 00
  • Ambient temperature
    -35 °C ... 60 °C
  • Pneumatic tubing test conditions
    Suitability for energy chains: >5 million cycles as per FN 942021
  • Min. bending radius
    33 mm
  • Material fire test
    UL94 HB
  • Product weight by length
    0.0767 kg/m
  • Material of pneumatic tubing
    TPE-U(PU)
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Pneumatic connection
    For plug connection outside diameter 12 mm
  • Tubing characteristics
    Suitable for energy chains in applications with high cycle rates
  • Inside diameter
    8 mm
  • Certification
    German Technical Control Board (TÜV)
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Color
    Red

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

178414 Related Documents

178414 DataSheet.pdf

Similar products from: Festo Pneumatic Tubing
