1732654 Festo Cable Assemblies
Part#:1732654
Alt. Part#:NEBM-M23G12-E-10-N-S1G9
Manufacturer:Festo
Category:Cable Assemblies
Product Lifecycle:Active
Product description
resolver cable NEBM-M23G12-E-10-N-S1G9 Suitable for servo motor EMMS-AS-... Cable identification: Without inscription label holder, Electrical connection 1, function: Field device side, Electrical connection 1, design: Round, Electrical connection 1, conn
Product Details
- Type code NEBM
- Electrical connection 1, connection type Socket
- Electrical connection 1, occupied pins/wires 6
- Electrical connection 2, connection type Plug
- Electrical connection 2, occupied pins/wires 7
- Cable length 10 m
- Cable designation Without label holder
- Electrical connection 1, cable outlet Straight
- Electrical connection 1, number of pins/wires 12
- Electrical connection 2, design Rectangular
- Electrical connection 2, number of pins/wires 9
- Nominal operating voltage DC 24 V
- Operating voltage range AC 0 V ... 30 V
- Degree of protection IP65
- CE marking (see declaration of conformity) As per EU RoHS directive
- Corrosion resistance class (CRC) 0 - No corrosion stress
- Electrical connection 2, function Control side
- Electrical connection 2, cable outlet Straight
- Cable characteristic Suitable for energy chains
- Nominal conductor cross section 0.5 mm² 0.14 mm²
- Note on materials RoHS-compliant
- Electrical connection 1, design Round
- Electrical connection for input 1, connection pattern 00995670
- DC operating voltage range 0 V ... 30 V
- Bending radius, flexible cable installation ≥ 98 mm
- Note on degree of protection IP30 for Sub-D plug In mounted state
- Contamination level 3
- Electrical connection 1, function Field device end
- Electrical connection 1, connection technology M23x1
- Electrical connection 2, connection technology Sub-D
- Electrical connection 2, connection pattern 00995639
- Nominal operating voltage AC 24 V
- Cable diameter 8.3 mm
- Ambient temperature -50 °C ... 80 °C
- Cable design 3 x (2 x 0.14 mm²) + 2 x (0.5 mm²) Shielded
- Ambient temperature with flexible cable installation -40 °C ... 75 °C
- Material of cable sheath TPE-U(PUR)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
