161405 Festo Flow Control Valves

Product Details

• Adjusting element
  Slotted screw
• Standard flow rate in flow control direction 6 -> 0 bar
  1265 l/min
• Valve function
  Flow control non-return function
• Standard nominal flow rate in flow control direction
  610 l/min
• Ambient temperature
  -20 °C ... 80 °C
• Explosion prevention and protection
  Observe the information on the certificate Zone 22 (ATEX)
• Permissible actuation moment, adjusting screw
  1.5 Nm
• Hollow bolt material
  High-alloy steel
• Pneumatic connection 1
  G1/4
• Type code
  CRGRLA
• Maritime classification
  See certificate
• Pneumatic connection 2
  G¼
• Mounting position
  Any
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4]
• For use in the food industry
  See supplementary material information
• Note on materials
  RoHS-compliant
• Material of adjusting screw
  High-alloy stainless steel
• Standard nominal flow rate in non-return direction
  450 l/min ... 820 l/min
• Operating pressure
  0.3 bar ... 10 bar
• Symbol
  00991452
Max. tightening torque
11 Nm
Seals material
FPM PVC
Type of mounting
Screw-in
Standard flow rate in non-return direction at 6 -> 0 bar
1030 l/min ... 1345 l/min
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Temperature of medium
-10 °C ... 60 °C
Product weight
71.6 g
Swivel joint material
High-alloy stainless steel
Storage temperature
-10 °C ... 40 °C
Nominal width
6 mm
