153413 Festo Pneumatic Fittings

153413 on Powermatic Associates
Festo

Part#:153413

Alt. Part#:QSRL-1/8-8

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

Product description

push-in L-fitting, rotatable QSRL-1/8-8 360° rotatable, with ball bearing, male thread with external hexagon. Size: Standard, Nominal size: 4,6 mm, Type of seal on screw-in stud: coating, Assembly position: Any, Container size: 1

Product Details

  • Nominal width
    4.6 mm
  • Temperature-dependent operating pressure
    -0.95 bar ... 14 bar
  • Ambient temperature
    0 °C ... 60 °C
  • Mounting position
    Any
  • Operating pressure for entire temperature range
    -0.95 bar ... 6 bar
  • Size
    Standard
  • Pack size
    1
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Max. radial torque
    0.015 Nm
  • Note on materials
    RoHS-compliant
  • Releasing ring material
    POM
  • Type code
    QSRL
  • Type of seal on screwed trunnion
    Coating
  • Max. rotational speed
    400 1/min
  • Product weight
    33 g
  • Housing material
    PBT
  • Maritime classification
    See certificate
  • Design
    Push-pull principle
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Max. tightening torque
    7 Nm
  • Releasing ring color
    Blue
  • Material of tubing seal
    NBR
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Pneumatic connection 1
    External thread R1/8
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 8 mm
  • Material of tube retaining claw
    High-alloy stainless steel

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
