152701 Festo Pneumatic Tubing

152701 on Powermatic Associates
Festo

Part#:152701

Alt. Part#:PAN-10X1,5-SI

Manufacturer:Festo

Category:Pneumatic Tubing

Product Lifecycle:Active

Product description

plastic tubing PAN-10X1,5-SI Standard O.D tubing, for QS plug connectors, CN and CK polyamide fittings (not approved for use in the food industry). Outside diameter: 10 mm, Bending radius relevant for flow rate: 58 mm, Inside diameter: 7 mm, Min. bending

Product Details

  • Maritime classification
    See certificate
  • Min. bending radius
    27 mm
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Color
    Silver
  • Outside diameter
    10 mm
  • Type code
    PAN
  • Certificate issuing authority
    B 013277 0506 00
  • Pneumatic tubing test conditions
    Suitability for energy chains: >5 million cycles as per FN 942021
  • Inside diameter
    7 mm
  • Ambient temperature
    -30 °C ... 80 °C
  • Pneumatic connection
    For plug connection outside diameter 10 mm
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Tubing characteristics
    Suitable for energy chains in applications with high cycle rates
  • Bending radius relevant for flow rate
    58 mm
  • Temperature-dependent operating pressure
    -0.95 bar ... 17 bar
  • Product weight by length
    0.042 kg/m
  • Material of pneumatic tubing
    TPE-A
  • Certification
    German Technical Control Board (TÜV)
  • Shore hardness
    D 55 +/-3

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

152701 Related Documents

152701 DataSheet.pdf
