JGH3250FAG Eaton Industrial Automation Components
Part#:JGH3250FAG
Manufacturer:Eaton
Category:Industrial Automation Components
Product Lifecycle:Active
Mar 15, 2025
Product description
JGH3250FAG Eaton - Eaton Series G complete molded case circuit breaker, JG Frame, 250 A, Three-pole, 600V, 100 kAIC at 240V, 70 kAIC at 415V, 65 kAIC at 480V, 25 kAIC at 600V, Line/load standard w/ metric mounting hardware, Fixed thermal, adj. magnetic
Product Details
- Weight 6 pounds
- Length 3.57 inches
- Trip Type Adjustable Magnetic, Fixed Thermal
- Type Complete Breaker
- Interrupt Rating 100 kiloamps, 25 kiloamps, 65 kiloamps
- Amperage 250 amperes
- Height 4.13 inches
- Maximum AC Voltage Rating: 600
- Volts: 600 VAC 50/60 Hertz
- Series: JG
- Interrupting Rating: 25 kA at 600 Volt AC
- Terminal Type: Line and Load
- Frame Type: JG
- Size: 3.57 Inch Length x 4.13 Inch Width x 4.13 Inch Height
- Poles: 3
- Amps: 32 A
- UPC: 782113526874
- Approval: IEC
- Type: Fixed Thermal
- Shipping Height: 5.00 In.
- Shipping Length: 10.00 In.
- Shipping Weight: 6.00
- Shipping Width: 7.00 In.
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
