Name: SOP-E12-150A
Brand: Banner

GV2P14

Schneider Electric GV2P14 is a Motor Protection Circuit Breaker (MPCB) within the GV2P sub-range, designed for thermal-magnetic motor protection and manual motor starting. It features 3 poles and provides protection functions against short-circuit and thermal overload. The rated current range is 6 - 10 A, with a rated insulation voltage (Ui) of 690 V. This MPCB is designed for DIN rail or mounting plate installation, has a net width of 45 mm, and is operated via a rotary knob. Protection settings for short-circuit pickup current are fixed at 138A. The rated impulse voltage (Uimp) is 6 kV, and it supports rated active powers of 3 kW at 400/415Vac, 5 kW at 500Vac, and 5.5 kW at 690Vac. The trip current rating is 10 AT, with a frame current rating of 32 AF. It boasts a mechanical durability of 100,000 operations at no load and an electrical durability of 100,000 operations at 415Vac in AC-3 condition. Connection is facilitated through screw-clamp terminals. The rated voltage for phase-to-phase is 690 V, with all three poles protected. The trip unit type is thermal-magnetic, supporting a minimum current of 6 A and a maximum current of 10 A, classified under utilisation category A AC-3.

Schneider Electric

10

EL1809

Beckhoff HD Ethercat Terminal, 16 Chnnl

Beckhoff

10

RSM-2RKM 40

Actuator and Sensor Tee, T-Splitter without Cable, , 7/8" minifast

Turck

10

53113530

53113530 - LAPP SKINTOP® COLD Strain Relief Cable Gland - M25 x 1.5

Lapp

2

LC1D115BD

Schneider Electric LC1D115BD is a magnetic contactor from the Deca sub-range, designed with screw connections and three poles (3P; 3NO). It features a rated current of 200A for AC-1 and 115A for 440Vac in AC-3 conditions. This contactor is suitable for DIN rail mounting and has a net width of 120 mm. It offers a degree of protection rated at IP20 and operates with a control voltage (DC) range of 18-28.8Vdc, with a nominal 24Vdc. The rated operating voltage (Ue) is up to 1000 V, and it includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 8 kV. Its rated active power capacity spans from 30kW at 220-230Vac to 80kW at 660-690Vac in AC-3 conditions, with additional ratings for specific voltages. It also features 1 normally closed (NC) auxiliary contact with contacts type of 1NO+1NC instantaneous aux. The rated power in horsepower (HP) ranges from 30HP at 200-208Vac to 100HP at 575-600Vac for 3-phase, 50Hz/60Hz, UL/CSA conditions. The mechanical durability of the LC1D115BD is rated at 8 million operations at no load, and its electrical durability with load is rated at 950,000 operations. The rated voltage for phase-to-phase AC conditions is 1000 V.

Schneider Electric

6

PKGTAB

Schneider Electric PKGTAB, Load center accessory, QO/Homeline, insulator kit, for ground bars

Schneider Electric

3

MQDC1-506

Cordset: Single Ended A-Code M12; 5-pin Straight Female Connector; 2 m (6.56 ft) Black PVC Jacket; Nickel-Plated Brass Coupling Nut

Banner

184

RSF RKF 57/22

DeviceNet™ Receptacle, Panel Feed-through, , Male 7/8″ minifast Receptacle, Female 7/8″ minifast Receptacle, Design: 7/8 adapter, 5-pin feedthrough male/female, For use in CAN (DeviceNet, CANopen) applications, Ampacity: 9 A, Rated voltage: 600 V, Temperature range: -40 °C…+105 °C, Protection class: NEMA 1, 3, 4 and IEC IP67, "

Turck

2
