S18DLRBWPT Banner Signal Beacons

Product Details

• Weight
  10.5233344 g
• Country Of Origin
  CN
• Wireless
  No
• IO Link
  No
• Feature: Quick Disconnect
  No
• Multi-Color Device
  Single Color On
• Feature: Chemical Resistant
  No
• Modbus RTU
  No
• Feature: Hazardous Area
  No
• Primary Window Material
  Polycarbonate Clear
• Feature: Washdown Rated
  Yes
• Environmental Rating
  IP67; IP69
• Input Type
  PNP
• Max Input Response Time (ms)
  1
• Number of Input Pins/Conductors
  4
• Color 1 - Wavelength/Color Temp/Coordinates
  525 nm
• Lumens Color 1
  2.3
• Cable Length (m)
  2
• Pro-Editor Compatible (Discrete)
  No
• Indication Intensity
  High Brightness & Daylight Visible
Feature: Audible
No
Physical Dimensions (LxWxH or DxH mm)
23.5 x 34.6
Min Op. Temperature (°C)
-40
Primary Housing Color
Black
Max Op. Temperature (°C)
50
NEMA Type and UL Type Rating
NEMA and UL 4X, 13
Supply Voltage
10-30 V dc
Color 3 - Wavelength/Color Temp/Coordinates
590 nm
Max Current Color (mA)
25
Lumens Color 3
1.2
Color Option 3
Yellow
Animation Option 1
Solid On
Color 2 - Wavelength/Color Temp/Coordinates
625 nm
Lumens Color 2
1.4
Connection
Terminal
Color Option 1
Green
Color Option 2
Red
Color Technology
Standard LED
Product Size (mm)
18
Number of Colors / Segments
3
Power Source
DC
Power
DC
Indication
Yes
Mounting Thread
M18 x 1.0
Color Input Control
Individual (One wire/color, same number of colors as input wires)
Primary Housing Material
Polycarbonate
Housing Style
Barrel Mount - Flat Window
