S18DLOXXPT Banner Signal Beacons

Name: S18DLOXXPT
Brand: Banner
Price: 49 USD
Availability: BackOrder

Part#:S18DLOXXPT

Manufacturer:Banner

Alt. Part#:31678

Product Lifecycle:Active

Get a quick Quote!

S18 DAYLIGHT VISIBLE EZ Light - 18 mm - IP67; Single Color: Orange; 10-30 V dc PNP Input; 4-screw Terminal Wiring

About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the S18DLOXXPT Banner price in the box on the right side or send a quick quote.

Product Details

Weight
63.50288 g
Country Of Origin
CN
Pro-Editor Compatible (Discrete)
No
Modbus RTU
No
Wireless
No
IO Link
No
Multi-Color Device
Single Color On
Indication Intensity
High Brightness & Daylight Visible
Feature: Chemical Resistant
No
Feature: Audible
No
Feature: Hazardous Area
No
Feature: Washdown Rated
Yes
Min Op. Temperature (°C)
-40
Primary Window Material
Polycarbonate Clear
Max Op. Temperature (°C)
50
Primary Housing Color
Black
NEMA Type and UL Type Rating
NEMA and UL 4X, 13
Environmental Rating
IP67; IP69
Physical Dimensions (LxWxH or DxH mm)
23.5 x 34.6
Max Input Response Time (ms)
1

Input Type

PNP

Color Option 1

Orange

Color 1 - Wavelength/Color Temp/Coordinates

608 nm

Color Technology

Standard LED

Number of Input Pins/Conductors

Supply Voltage

10-30 V dc

Lumens Color 1

0.90

Max Current Color (mA)

Connection

Terminal

Animation Option 1

Solid On

Product Size (mm)

Color Input Control

Individual (One wire/color, same number of colors as input wires)

Number of Colors / Segments

Indication

Yes

Mounting Thread

M18 x 1.0

Primary Housing Material

Polycarbonate

Power Source

Housing Style

Barrel Mount - Flat Window

Power

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

S18DLOXXPT Description

Banner Engineering S18DLOXXPT, part of the EZ-LIGHT series, is a pilot light designed with daylight-visible 1-color orange LED illumination. This unit features a clear Polycarbonate (PC) window and base, with a black housing. It has an 18mm indicator diameter and utilizes a screw-clamp terminal connection for installation. The S18DLOXXPT operates on a supply voltage range of 10Vdc to 30Vdc, with a nominal range of 12Vdc to 24Vdc, and is designed for flush mounting in an 18mm hole with an M18 thread. It is capable of operating in ambient air temperatures ranging from -40°C to +50°C. This model offers a high degree of protection with ratings of IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13, ensuring its durability in various environments. The shape is characterized by a round protruding window and a threaded cylindrical barrel. It has a current consumption of 25mA and includes 1 x digital input (10-30Vdc; PNP) for color control.
