S18DLGRYNT Banner Signal Beacons

S18DLGRYNT on Powermatic Associates
Banner
  • S18DLGRYNT
  • S18DLGRYNT

Part#:S18DLGRYNT

Alt. Part#:31687

Manufacturer:Banner

Category:Signal Beacons

Product Lifecycle:Active

Product description

S18 DAYLIGHT VISIBLE EZ Light - 18 mm - IP67; Three Color: Green Red Yellow; 10-30 V dc NPN Input; 4-screw Terminal Wiring

Product Details

  • Weight
    63.50288 g
  • Country Of Origin
    CN
  • Pro-Editor Compatible (Discrete)
    No
  • Wireless
    No
  • IO Link
    No
  • Modbus RTU
    No
  • Feature: Quick Disconnect
    No
  • Multi-Color Device
    Single Color On
  • Indication Intensity
    High Brightness & Daylight Visible
  • Feature: Chemical Resistant
    No
  • Feature: Audible
    No
  • Feature: Hazardous Area
    No
  • Primary Window Material
    Polycarbonate Clear
  • Feature: Washdown Rated
    Yes
  • Primary Housing Color
    Black
  • Min Op. Temperature (°C)
    -40
  • Max Op. Temperature (°C)
    50
  • NEMA Type and UL Type Rating
    NEMA and UL 4X, 13
  • Physical Dimensions (LxWxH or DxH mm)
    23.5 x 34.6
  • Environmental Rating
    IP67; IP69
  • Max Input Response Time (ms)
    1
  • Input Type
    NPN
  • Supply Voltage
    10-30 V dc
  • Number of Input Pins/Conductors
    4
  • Color 3 - Wavelength/Color Temp/Coordinates
    590 nm
  • Max Current Color (mA)
    25
  • Color Option 3
    Yellow
  • Lumens Color 3
    1.2
  • Color 2 - Wavelength/Color Temp/Coordinates
    625 nm
  • Color 1 - Wavelength/Color Temp/Coordinates
    525 nm
  • Lumens Color 2
    1.4
  • Connection
    Terminal
  • Color Option 2
    Red
  • Lumens Color 1
    2.3
  • Animation Option 1
    Solid On
  • Color Option 1
    Green
  • Color Technology
    Standard LED
  • Product Size (mm)
    18
  • Cable Length (m)
    2
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Number of Colors / Segments
    3
  • Mounting Thread
    M18 x 1.0
  • Power Source
    DC
  • Housing Style
    Barrel Mount - Flat Window
  • Primary Housing Material
    Polycarbonate
  • Indication
    Yes
  • Power
    DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of S18DLGRYNT on Powermatic Associates is $54.00. Order now.

About the product

Banner Engineering S18DLGRYNT is a pilot light from the EZ-LIGHT series, featuring a daylight-visible 3-color G/R/Y color pattern LED illumination. This part is designed with a clear Polycarbonate (PC) window and a Polycarbonate (PC) base, housed in a black casing. It has an 18mm indicator diameter and utilizes a screw-clamp terminal connection for installation. The S18DLGRYNT operates on a supply voltage range of 10Vdc to 30Vdc, with a nominal range of 12Vdc to 24Vdc, and is designed for flush mounting in an 18mm hole with an M18 thread. It can operate in ambient air temperatures ranging from -40°C to +50°C. This part is protected to IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13 standards, ensuring durability in various environments. The shape of the S18DLGRYNT is characterized by a round protruding window and a threaded cylindrical barrel. It has a current consumption of 25mA and includes 3 digital inputs (10-30Vdc; NPN) for color control.

S18DLGRYNT Related Documents

160690.pdf
