M18XXGPQPMA Banner Indicator Lights

M18XXGPQPMA on Powermatic Associates
Banner

Part#:M18XXGPQPMA

Alt. Part#:76842

Manufacturer:Banner

Category:Indicator Lights

Product Lifecycle:Active

Product description

M18 Series EZ-LIGHT: 1-Color General Purpose Indicator; Voltage: 10-30 V dc; Housing: Nickel-Plated Brass; Input: PNP; Color: Green; 150 mm (6 in) 4-pin M12 PUR Pigtail QD

Product Details

  • Weight
    113.398 g
  • Country Of Origin
    US
  • Multi-Color Device
    Single Color On
  • Primary Window Material
    Thermoplastic Diffused
  • Input Type
    PNP
  • Mounting Thread
    M18 x 1.0
  • Feature: Quick Disconnect
    Yes
  • Pro-Editor Compatible (Discrete)
    No
  • Wireless
    No
  • Modbus RTU
    No
  • IO Link
    No
  • Feature: Chemical Resistant
    No
  • Feature: Hazardous Area
    No
  • Feature: Audible
    No
  • Min Op. Temperature (°C)
    -40
  • Max Op. Temperature (°C)
    50
  • Environmental Rating
    IP67
  • Physical Dimensions (LxWxH or DxH mm)
    16.5 x 51.5
  • Max Input Response Time (ms)
    1
  • Connection
    Pigtail PUR QD
  • Number of Input Pins/Conductors
    4
  • Supply Voltage
    10-30 V dc
  • Max Current Color (mA)
    25
  • Color Option 3
    Green
  • Product Size (mm)
    18
  • Quick Disconnect Type
    M12 (Euro)
  • Color Technology
    Standard LED
  • Primary Housing Material
    Nickel-Plated Brass
  • Indication
    Yes
  • Number of Colors / Segments
    1
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Power Source
    DC
  • Cable Length (m)
    2
  • Housing Style
    Barrel Mount - Flat Window
  • Power
    DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of M18XXGPQPMA on Powermatic Associates is $125.00. Order now.

About the product

Banner Engineering M18XXGPQPMA, part of the EZ-LIGHT series, is a pilot light designed with a 1-color Green LED illumination for clear visibility. It features a black housing with a round protruding window and a threaded cylindrical barrel. The construction includes a thermoplastic diffused window, nickel-plated brass housing, and a polyurethane (PUR) cable sheath for durability. It is pre-wired with a 6" / 15cm PUR pigtail that terminates with a 4-pin M12 Euro-style QD connector, facilitating easy and secure connections. This pilot light operates on a supply voltage of 10Vdc-30Vdc (12Vdc-24Vdc nom.) and is designed for flush mounting in an 18mm hole with an M18 thread. The indicator has a diameter of 18mm and can operate in ambient air temperatures ranging from -40°C to +50°C. It offers a degree of protection of IP67, making it suitable for use in environments where dust and moisture resistance is required. The current consumption is 25mA, and it includes 1 x digital input (10-30Vdc; PNP) for color control.

M18XXGPQPMA Related Documents

121903.pdf

This item can ship within 0 day!

Manufacturer warranty

M18XXGPQPMA Banner

$125.00

Your price can be lower.
Log in or Create account to check your discount

Stock:

0

Select Qty:

$125.00

$125.00 each

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
