M18RGX7PQPMA Banner Indicator Lights

M18RGX7PQPMA on Powermatic Associates
Banner

Part#:M18RGX7PQPMA

Manufacturer:Banner

Alt. Part#:74287

Product Lifecycle:Active

Get a quick Quote!

M18 Series EZ-LIGHT: 2-Color Sensor Emulator Indicator; Nickel-Plated Brass Housing M18x1 Thread; IP67; Input: PNP; Colors: Red Green; 150 mm (6 in) 4-pin M12 PUR Pigtail QD

About the manufacturer: Banner is one of the manufacturers that offers Indicator Lights that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the M18RGX7PQPMA Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    81.64656 g
  • Country Of Origin
    US
  • Pro-Editor Compatible (Discrete)
    No
  • Feature: Hazardous Area
    No
  • Wireless
    No
  • Application: Photoelectric Sensors
    Yes
  • Feature: Quick Disconnect
    Yes
  • Modbus RTU
    No
  • Feature: Chemical Resistant
    No
  • IO Link
    No
  • Feature: Audible
    No
  • Multi-Color Device
    Single Color On
  • Primary Window Material
    Thermoplastic Diffused
  • Min Op. Temperature (°C)
    -40
  • Max Op. Temperature (°C)
    50
  • Physical Dimensions (LxWxH or DxH mm)
    16.5 x 51.5
  • Input Type
    PNP
  • Max Input Response Time (ms)
    1
  • Supply Voltage
    10-30 V dc
  • Environmental Rating
    IP67
  • Number of Input Pins/Conductors
    4
  • Quick Disconnect Type
    M12 (Euro)
  • Color Option 2
    Green
  • Connection
    Pigtail PUR QD
  • Max Current Color (mA)
    25
  • Product Size (mm)
    18
  • Color Option 1
    Red
  • Animation Option 1
    Solid On
  • Color Technology
    Standard LED
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Number of Colors / Segments
    2
  • Mounting Thread
    M18 x 1.0
  • Primary Housing Material
    Nickel-Plated Brass
  • Power Source
    DC
  • Housing Style
    Barrel Mount - Flat Window
  • Indication
    Yes
  • Power
    DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

M18RGX7PQPMA Description

Banner Engineering M18RGX7PQPMA is a pilot light from the EZ-LIGHT series designed as a phot-electric sensor emulator with a 2-color R/G color pattern LED illumination. It features a black housing with a round protruding window and a threaded cylindrical barrel. The material composition includes a thermoplastic diffused window, nickel-plated brass housing, and a polyurethane (PUR) cable sheath. This part is pre-wired with a 6" / 15cm PUR pigtail terminated with a 4-pin M12 Euro-style QD connector. It operates on a supply voltage of 10Vdc-30Vdc (12Vdc-24Vdc nom.) and is designed for flush mounting in an 18mm hole with an M18 thread. The indicator has a diameter of 18mm and can operate in ambient air temperatures ranging from -40°C to +50°C. It is rated with a degree of protection of IP67, consumes 25mA of current, and includes 2 x digital inputs (10-30Vdc; PNP) for color control.

Related documents M18RGX7PQPMA Specs

M18RGX7PQPMA 121903.pdf

Manufacturer warranty

$118.00

Request a quote, and we will send availability within minutes.

Select Qty:

$118.00

$118.00 each

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
