LEDWLA580XD6-XQ Banner Vision Accessories

LEDWLA580XD6-XQ on Powermatic Associates
Banner

Part#:LEDWLA580XD6-XQ

Manufacturer:Banner

Alt. Part#:13956

Product Lifecycle:Active

Get a quick Quote!

Vision Light - 580 mm Linear Array - IP50; 24 High Intensity White LEDs - 24 V dc; Diffusing Plastic Window; Requires Cable MQDC20-xxx

About the manufacturer: Banner is one of the manufacturers that offers Vision Accessories that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the LEDWLA580XD6-XQ Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    1360.776 g
  • Country Of Origin
    MX
  • Lens Focusing Angle (°)/Field of View
    6.5
  • Max Op. Temperature (°C)
    50
  • Max Current Color (mA)
    2000
  • Color Technology
    Standard LED
  • Supply Voltage
    24 V DC
  • Physical Dimensions (LxWxH or DxH mm)
    623.6 x 59.4 x 32.6
  • Power
    DC
  • Device Type
    Bar Light
  • Primary Housing Material
    Anodized Aluminum
  • QD Type/Cable Length
    M12 (Euro) requires mating cordset
  • Color
    White
  • Number of Input Pins/Conductors
    5
  • Connection Type
    Integral QD
  • Housing Style
    Linear Strip
  • Window Material
    Diffuse Acrylic

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

LEDWLA580XD6-XQ Description

Banner Engineering LEDWLA580XD6-XQ is an illumination unit designed for linear array illumination backlight applications. It features a high-intensity design with a 580mm (22.8 inches or approximately 2 feet) array length. The unit emits visible white light and has a rectangular shape. It is constructed with a black anodized aluminum housing and a diffused acrylic window. This product is pre-equipped with a 5-pin Euro-style M12 connector for connectivity. It operates on a 24Vdc supply voltage and has an IP50 degree of protection.

Related documents LEDWLA580XD6-XQ Specs
