LEDBRV80X80M Banner Vision Accessories

LEDBRV80X80M on Powermatic Associates
Banner

Part#:LEDBRV80X80M

Manufacturer:Banner

Alt. Part#:97376

Product Lifecycle:Active

Get a quick Quote!

VE Series 80 x 80 mm Ring Light; Visible Blue LED; 24 V dc; 0.3 m (1 ft) Cable with 3-pin male Connector; Connects to VE Smart Camera

About the manufacturer: Banner is one of the manufacturers that offers Vision Accessories that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the LEDBRV80X80M Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    217.72416 g
  • Country Of Origin
    MX
  • Max Current Color (mA)
    250
  • Feature: Quick Disconnect
    Yes
  • Color Technology
    Standard LED
  • Physical Dimensions (LxWxH or DxH mm)
    87.3 x 87.3 x 35.5
  • Supply Voltage
    24 V dc
  • Max Op. Temperature (°C)
    50
  • Number of Input Pins/Conductors
    3
  • QD Type/Cable Length
    300 mm; M8 (Pico)
  • Connection Type
    Pigtail QD
  • Window Material
    Acrylic
  • Color
    Blue
  • Device Type
    Ring Light
  • Housing Style
    Rectangular
  • Primary Housing Material
    Aluminum
  • Power
    DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

LEDBRV80X80M Description

Banner Engineering LEDBRV80X80M is an illumination unit designed for ring illumination light applications. This product features a square shape with dimensions of 80x80mm and emits visible blue light. It is constructed with an aluminium housing and an acrylic window for durability. The unit is pre-wired with a 12" / 300mm pigtail that terminates with a 3-pin Pico-style M8 connector, facilitating easy installation. It operates on a supply voltage of 24Vdc.

Related documents LEDBRV80X80M Specs

LEDBRV80X80M 192656.pdf

Manufacturer warranty

$395.00

Request a quote, and we will send availability within minutes.
