K50CAPT2GBYF2Q Banner Pick-to-Light Sensors

K50CAPT2GBYF2Q on Powermatic Associates
Banner

Part#:K50CAPT2GBYF2Q

Manufacturer:Banner

Alt. Part#:805048

Product Lifecycle:Active

Get a quick Quote!

K50 Compact Series: 3-Input-Color Touch Sensor Gen 2; Voltage: 12-30 V dc; Housing: Polycarbonate; IP67 IP69K; Input: PNP (NO); Colors: Green Blue Yellow; 8-pin M12 Integral QD

About the manufacturer: Banner is one of the manufacturers that offers Pick-to-Light Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the K50CAPT2GBYF2Q Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    99.79024 g
  • Country Of Origin
    MX
  • Multi-Color Device
    Single Color On
  • Feature: Audible
    No
  • Feature: Chemical Resistant
    No
  • Primary Window Material
    Polycarbonate Diffused
  • Pro-Editor Compatible (Discrete)
    No
  • Wireless
    No
  • IO Link
    No
  • Feature: Quick Disconnect
    Yes
  • Modbus RTU
    No
  • Feature: Hazardous Area
    No
  • Feature: Washdown Rated
    Yes
  • Button Operation
    Momentary
  • Primary Housing Color
    Black
  • Storage Temp (°C)
    -40 to 70
  • Min Op. Temperature (°C)
    -40
  • Max Op. Temperature (°C)
    50
  • Max Op. Relative Humidity Non-Condensing (%)
    90% @ 50°C
  • Environmental Rating
    IP67; IP69
  • Operation
    Normally Open
  • Supply Voltage
    12-30 V dc
  • Pick-to-Light Function
    F2
  • Physical Dimensions (LxWxH or DxH mm)
    50.0 x 48.0
  • Max Output Response Time (ms)
    50
  • Input Type
    PNP
  • Number of Input Pins/Conductors
    8
  • Max Current Color (mA)
    75
  • Color 3 - Wavelength/Color Temp/Coordinates
    591 nm
  • Output Type
    PNP
  • Color Option 3
    Yellow
  • Color 2 - Wavelength/Color Temp/Coordinates
    465 nm
  • Lumens Color 3
    24.0
  • Color Option 2
    Blue
  • Product Size (mm)
    50
  • Quick Disconnect Type
    M12 (Euro)
  • Color 1 - Wavelength/Color Temp/Coordinates
    525 nm
  • Connection
    Integral QD
  • Lumens Color 1
    29.0
  • Animation Option 1
    Solid On
  • Color Option 1
    Green
  • Color Technology
    Standard LED
  • Number of Colors / Segments
    3
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Actuation
    Yes
  • Activation Function
    Capacitive Touch
  • Mounting Thread
    M30 x 1.5
  • Primary Housing Material
    Polycarbonate
  • Housing Style
    Base Mount - Flat Window
  • Power Source
    DC
  • Power
    DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

K50CAPT2GBYF2Q Description

Banner Engineering K50CAPT2GBYF2Q, part of the EZ-LIGHT series, is a capacitive touch-sensitive pick-to-light device designed with a flat-top Gen.2 LED illumination. It features a black housing with a flat window shape, constructed from polycarbonate (PC) for both the diffused window and the base. This part is pre-wired with a 2m / 6.5ft 5-wire cable that terminates with bare end flying leads, supporting a supply voltage range of 12Vdc-30Vdc (24Vdc nominal). It offers versatile mounting options including surface or base pole with an M30 thread and has a diameter of 50mm / 2". The device operates within an ambient air temperature range of -40°C to +50°C and is rated with a degree of protection of IP67 and IP69K. Its operating mode includes a momentary job light (G; Green) that remains on when the input is active, and touch activates the output only with a Normally Open (NO) touch output. The current consumption is 75mA, and it features 1 x digital input (12-30Vdc; NPN) for JOB color control and 1 x digital output (12-30Vdc; NPN) for touch functionality.

Related documents K50CAPT2GBYF2Q Specs

K50CAPT2GBYF2Q 189830.pdf
