Ixxat by HMS Networks 1.01.0281.12002 is a gateway featuring an active USB-to-CAN V2 interface. It operates with a USB 2.0 Hi-Speed PC bus interface and is powered by a 32bit microcontroller. The internal CAN controller supports CAN 2.0 A/B with baud rates ranging from 10kBit/s to 1Mbit/s. It includes a CAN high-speed transceiver (TI SN65HVD251D), a CAN low-speed transceiver (TJA1055T), and a LIN transceiver (TJA1020) that supports LIN protocol V1.3 and V2.0 with a maximum LIN baud rate of 20kBaud. The device offers galvanic isolation of 1000Vdc for 1s or 500Vac for 1min and is powered by a 5V max. 300mA supply via the USB port. Fieldbus connection complies with CiA 303-1 standards. It features a single RJ45 connector for CAN and a USB 2.0 Hi-speed connector. The compact device includes galvanically-isolated fieldbus, 2 x LED indicators, and operates within a temperature range of -20 to +70°C for speed and -40 to +85°C for control voltage. It has an IP40 degree of protection, with dimensions of H80mm x W50mm x D22mm, housed in a plastic (ABS) casing. The communication protocol supports 10kbit/s to 1Mbit/s for the CAN HS port and 480Mbit/s for the USB interface. It is designed for surface mounting and can operate in 10-95% relative humidity (RH), non-condensing environments.

HMS eWon component

HMS eWon component

HMS eWon component

HMS eWon component

Anybus by HMS Networks AB7500-F is a gateway belonging to the X-gateway series designed for protocol translation. It functions as a PROFIBUS master and a PROFINET-IRT device, featuring Ethernet dual-port cut-through switch technology. The device is configured via a USB port using the Anybus Configuration Manager software and requires installation in a vertical or flat position with galvanic isolation on both BUS/Ethernet sides. It includes 10 LED indicators for monitoring fieldbus, sub-network, and device status. The AB7500-F operates on a supply voltage of 19.2-28.8Vdc (24Vdc nominal) and has dimensions of H127mm x W44mm x D114mm. Its housing is made from aluminium and plastic, ensuring durability and resilience. Connection options include 2 x RJ45 connectors for 10/100Mbit/s Ethernet (full duplex, fixed), 1 x 9-pin D-sub female connector for PROFIBUS, 1 x 9-pin D-sub male connector for PROFIBUS and RS-232 configuration, 1 x 2-poles 5.08mm plug-in screw connector for power, and 1 x USB connector. The AB7500-F is designed for DIN rail mounting, offers an IP20 NEMA 1 degree of protection, and supports PROFIBUS and PROFINET communication protocols. It operates within an ambient air temperature range of -25 to +65 °C, with a current consumption of 400mA (max) and 200mA (typical). The device is suitable for environments with 5-95% relative humidity (non-condensing) and can store in temperatures ranging from -40 to +85 °C. Its Ethernet and PROFIBUS speeds are 10/100Mbit/s and up to 12Mbit/s, respectively.

Anybus by HMS Networks AB7517-F is a gateway within the X-gateway series designed for protocol translation. It features a vertical or flat installation position with galvanic isolation on both BUS/Ethernet sides. The I/O configuration is manageable via USB port using Anybus Configuration Manager software. This device integrates InterBus Fiber Optic and PROFINET-IRT with an Ethernet dual-port cut-through switch, 10 LED indicators for fieldbus/sub-network/device status, and a baud rate jumper. It operates on a supply voltage of 19.2-28.8Vdc (24Vdc nominal) and has dimensions of H127mm x W44mm x D114mm. The housing is made from aluminium and plastic, and connection options include 2 RJ45 connectors for 10/100Mbit/s Ethernet (full duplex, fixed), 2 fiber optic TX connectors, 2 fiber optic RX connectors, a 2-poles 5.08mm plug-in screw connector for power, and a USB connector. It offers an IP20 NEMA 1 degree of protection and is suitable for DIN rail mounting. The communication protocols supported are INTERBUS and PROFINET, with an ambient air temperature for operation ranging from -25 to +65 °C. The current consumption is 400mA (max) and 200mA (typical) at 24Vdc. It is designed for storage in temperatures ranging from -40 to +85 °C and can operate at speeds of 10/100Mbit/s (PROFINET) and 500kbit/s to 2Mbit/s (INTERBUS). The device is designed to withstand 5-95% relative humidity (RH; non-condensing).

Anybus by HMS Networks AB7699-F is a gateway belonging to the X-gateway series designed as a protocol translator between EtherNet/IP and EtherCAT networks. It is configured for vertical or flat installation with galvanic isolation on both BUS/Ethernet sides. The I/O configuration is managed via a USB port using the Anybus Configuration Manager software. This model features an EtherNet/IP scanner and EtherCAT slave functionality, equipped with 8 IP configuration switches and 10 LED indicators for comprehensive fieldbus, sub-network, and device status monitoring. It operates on a supply voltage of 19.2-28.8Vdc (24Vdc nominal) and has dimensions of H127mm x W44mm x D114mm. The housing is made from aluminium and plastic, ensuring durability and resilience. Connection options include 2 x RJ45 connectors for 100Mbit/s full duplex EtherCAT, 1 x RJ45 LAN connector for 10/100Mbit/s Ethernet/IP with both full and half duplex capabilities, 1 x 2-poles 5.08mm plug-in screw connector for power, and 1 x USB connector for configuration. It offers an IP20 and NEMA 1 degree of protection and is designed for DIN rail mounting. The AB7699-F supports communication protocols of EtherCAT and Ethernet/IP, operates within an ambient air temperature range of -25 to +65 °C for operation and -40 to +85 °C for storage. It has a current consumption of 400mA (max) and 200mA (typical) at 24Vdc, with a speed of 100Mbit/s for EtherCAT and 10/100Mbit/s for Ethernet. The device is designed to function in environments with 5-95% relative humidity (non-condensing).

Anybus by HMS Networks AB7866-F is a gateway within the X-gateway series designed for protocol translation. It features a ControlNet adapter and an Interbus CU slave, allowing for vertical or flat installation with galvanic isolation on both BUS/Ethernet sides. Configuration is managed via a USB port using Anybus Configuration Manager software. The device includes 2 configuration switches (x10 / x1), 10 LED indicators for fieldbus, sub-network, and device status, and a baud rate jumper. It operates on a supply voltage of 19.2-28.8Vdc (24Vdc nom.) and has dimensions of H127mm x W44mm x D114mm. The housing is made from aluminium and plastic, with connection options including 2 ControlNet channel connectors, 1 9-pin D-sub male connector for Interbus bus-in, 1 9-pin D-sub female connector for Interbus bus-out, 1 2-poles 5.08mm plug-in screw connector for power, 1 USB connector, and 1 NAP connector. It offers an IP20 NEMA 1 degree of protection and is designed for DIN rail mounting. The communication protocols supported are ControlNet and INTERBUS, with an ambient air temperature for operation ranging from -25 to +65°C. Current consumption is 400mA (max) and 200mA (typical) at 24Vdc, with storage temperature tolerance from -40 to +85°C. The speed supported is 5Mbit/s for ControlNet and 500kbit/s to 2Mbit/s for INTERBUS, in environments with 5-95% relative humidity (non-condensing).

Anybus by HMS Networks AB7877-F is a gateway belonging to the X-gateway series designed for protocol translation. It functions as both a FIPIO slave and a Modbus RTU slave. This gateway is equipped with 13 configuration switches, 2 node address switches for precise adjustments, and 10 LED indicators to display fieldbus, sub-network, and device status. It supports an I/O configuration via a USB port using the Anybus Configuration Manager software and requires a vertical or flat installation position with galvanic isolation on both BUS/Ethernet sides. The AB7877-F operates on a supply voltage of 19.2-28.8Vdc, with a nominal 24Vdc, and features a compact design with dimensions of H127mm x W44mm x D114mm. The housing is made from aluminium and plastic, ensuring durability within its operational environment. Connection options include a 9-pin D-sub male connector for FIPIO, a 9-pin D-sub female connector for serial RS-232/RS-485 (Modbus RTU), a 2-poles 5.08mm plug-in screw connector for power, and a USB connector for configuration. It offers an IP20 NEMA 1 degree of protection and is suitable for DIN rail mounting. The AB7877-F supports communication protocols such as FIPIO, Modbus RTU, and RS-485, with operational speeds of 1Mbit/s for FIPIO and 12kbit/s to 57.6kbit/s for Modbus. It operates within an ambient air temperature range of -25 to +65 °C, has a current consumption of 400mA (max) or 200mA (typical), and can be stored in temperatures ranging from -40 to +85 °C. The device is designed to function in environments with 5-95% relative humidity (non-condensing).
