K30 Series EZ-LIGHT: 3-Color General Purpose Indicator; Voltage: 10-30 V dc; Housing: Polycarbonate; IP67 IP69K; Input: NPN; Colors: Green Red Yellow; 2 m (6.5 ft) Integral Cable

Aluminum Back Panel 10x8

APQS18-020H APERTURE QS18 SERIES - QTY 6

Banner Engineering DX80DR9M-H12C is a Gateway designed for surface mounting with a polycarbonate housing, polycarbonate rotary dial cover, polyester labels, EDPM rubber cover gasket, and nitrile rubber. It operates within an ambient air temperature range of -40 to +85°C and offers a degree of protection rated at IP20 NEMA 1. The dimensions of this rectangular-shaped gateway are H44.5mm x W103.3mm x D80.1mm. It features 2 digital outputs (30Vdc; NMOS; 1A), 2 analog inputs (0-20mA), and 1 analog input (Thermistor 10kΩ). The DX80DR9M-H12C operates on a 900 MHz transmission frequency with 2 digital inputs (30Vdc 3mA; NPN). It is part of the MultiHop Modbus IO data radios sub-range and incorporates MultiHop flexpower data radio functionality. The design includes SDI-12 data collection, 2 buttons, 2 bi-color LEDs for Ex e II applications, and utilizes FHSS (Frequency Hopping Spread Spectrum) technology. Connection is facilitated through detachable screw-clamp connectors and an RP-SMA connector. The supply voltage requirement is 10-30Vdc (12Vdc-24Vdc nom.), and it supports RS-485 Modbus TCP communication protocol. The frequency is set at 900MHz ISM band 1W, capable of a maximum transmission distance of 9.6km at nominal emission power.

Banner Engineering DX80ER2M-H is a Gateway designed for surface mounting, featuring a polycarbonate housing, polycarbonate rotary dial cover, polyester labels, EDPM rubber cover gasket, and nitrile rubber. It operates within an ambient air temperature range of -40 to +85°C and offers a degree of protection rated at IP20 NEMA 1. The dimensions of this rectangular-shaped gateway are H41.3mm x W80.14mm x D80.14mm. It utilizes a transmission frequency of 2400 MHz and is part of the MultiHop Modbus IO data radios sub-range. The design includes 2 buttons, 2 bi-color LEDs, and employs FHSS (Frequency Hopping Spread Spectrum) technology for enhanced communication reliability. Connection options include an RJ45 connector for Ethernet, screw connections, and an RP-SMA connector. The supply voltage requirement is 12-30Vdc (12Vdc-24Vdc nom.), and it supports communication protocols such as RS-485, RS-232, Modbus RTU, Modbus TCP, and Ethernet/IP. Operating on a frequency of 2.4GHz ISM band at 65mW, it can achieve a maximum transmission distance of 3.2km at nominal emission power.

Banner Engineering LEDBSW is an illumination unit designed as a circular spot light that emits visible blue light. It features a black anodized aluminum housing with a glass window for durability and clarity. This unit is pre-wired with a 6.5ft / 2m cable that terminates in bare end flying leads for easy installation. It operates on a supply voltage range of 10Vdc to 30Vdc, with nominal values at 12Vdc and 24Vdc. The diameter of the light spot produced by the LEDBSW is 29.5mm, making it suitable for applications requiring focused illumination in a compact form factor.

Banner Engineering K50APFF100GRC, part of the EZ-LIGHT series, is a pick-to-light device designed with a fixed field infrared (IR) sensing LED illumination for optical sensing applications. It features a black housing with a dome window shape, constructed from polycarbonate (PC) for both the diffused window and the base. This unit is pre-wired with a 2m / 6.5ft 4-wire cable terminated with bare end flying leads, supporting a supply voltage range of 12Vdc-30Vdc (24Vdc nom.). It offers versatile mounting options including surface, base pole M30, and 1/2" NPSM thread, with a 50mm / 2" dome diameter. The K50APFF100GRC operates effectively in ambient air temperatures ranging from -40°C to +50°C and boasts a high degree of protection with ratings of IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13. Its operating mode includes a momentary job light (G; Green) that is ON when the job input is active, and touch activates the output and sensing light (R; Red) with a NO (Normally Open) touch output. The device has a current consumption of 75mA, includes 1 x digital input (12-30Vdc; PNP) for JOB color control, offers a 100mm sensing range, and provides 1 x digital output (12-30Vdc; PNP) for touch functionality.

Banner Engineering Q25SP6LP W/30 is a polarized photo-electric sensor designed for retro-reflective mode operation. It features an M18 threaded mount for secure installation and is equipped with a pre-wired 30ft / 9m cable that terminates with bare end flying leads for easy connection. This sensor operates within an ambient air temperature range of -40 to +70°C and is housed in a thermoplastic casing with an acrylic lens, ensuring durability. It belongs to the Q25 DC series and offers a sensing distance of up to 2m with visible red light at a wavelength of 680 nm. The Q25SP6LP W/30 operates on a supply voltage of 10Vdc to 30Vdc, with nominal voltages of 12Vdc and 24Vdc, and features a rectangular shape. It provides a high degree of protection with an IP69K NEMA 6P rating. This sensor supports both Light-ON and Dark-ON operating modes and includes 1 x digital output (PNP transistor; complementary NO/NC) with a quick response time of 3ms / 0.003 s.

Q45UR Discrete Series: Kit, Includes: Controller Q45UR3BA63C Sensor: S18C2.0, Range: 50 - 250 mm; Input: 12 - 24 V dc; Output: Bipolar - 1 NPN 1 PNP, 9 m (30 ft) Cable

SLSP14-150Q85 EZ-SCREEN Pair With Test Input, Range: 0.1 to 6 m (4 INCH to 20FT); Height:150 mm (5.9 INCH), Response Time: (Tr) 11 ms; Number Of Beams: 20, Quick-Disconnect Connector: 5-Pin Emiter; 8-Pin Receive
