Contactors

Schneider Electric LC1DT60A3V7 is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminal design for secure connections. It is equipped with spring connections for control and screw connections for power, ensuring a robust connection system. This 4-pole (4NO) contactor is designed to handle a rated current of 60A (AC-1) and can be mounted on a DIN rail. With a net width of 70 mm and an IP20 degree of protection, it is compact and offers basic protection against touch. The control voltage ranges from 320-440Vac at 50Hz and 340-440Vac at 60Hz, with a nominal voltage of 400Vac. It includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, both rated for instantaneous operation. The contactor is capable of withstanding a rated impulse voltage (Uimp) of 6 kV and has a mechanical durability of 6 million operations at no load. The rated voltage for phase-to-phase connections is up to 690 V.

Schneider Electric LC1DT60A3MD is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminal design for secure connections. It is equipped with spring connections for control and screw connections for power, ensuring a robust connection system. This 4-pole (4NO) contactor is designed to handle a rated current of 60A under AC-1 conditions and can be mounted on a DIN rail. The unit has a net width of 70 mm and offers a degree of protection rated at IP20. It operates with a control voltage range of 165-275Vdc, with a nominal voltage of 220Vdc, and is designed to work within 0.75 to 1.25 times the control voltage (Uc). The LC1DT60A3MD includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC), enhancing its functionality. It boasts a mechanical durability of 6 million operations at no load and can accommodate rated impulse voltages up to 6 kV. The rated voltage for phase-to-phase connections is up to 690 V AC, making it suitable for a wide range of applications.

Schneider Electric LC1DT60A3F7 is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminal design for secure connections. It is equipped with spring connections for control and screw connections for power, ensuring a reliable installation. This 4-pole (4NO) contactor is designed to handle a rated current of 60A (AC-1) and can be mounted on a DIN rail. With a net width of 70 mm and an IP20 degree of protection, it is compact and suitable for various applications. The control voltage ranges from 88-121Vac at 50Hz and 93.5-121Vac at 60Hz, with a nominal voltage of 110Vac. It includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, both rated for 6 kV impulse voltage and designed for instantaneous operation. The contactor supports a mechanical durability of 6 million operations at no load and can operate at a phase-to-phase rated voltage of up to 690 V.

Schneider Electric LC1DT60A3FD is a magnetic contactor within the Deca sub-range, featuring EverLink(TM) terminal design for secure connections. It is equipped with spring connections for control and screw connections for power, ensuring a robust installation. This 4-pole (4NO) contactor is designed to handle a rated current of 60A under AC-1 conditions and can be mounted on a DIN rail. With a net width of 70 mm and an IP20 degree of protection, it is compact and offers basic protection against touch. The control voltage ranges from 82.5-137.5Vdc, with a nominal voltage of 110Vdc, allowing for flexibility in control voltage requirements. It includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, both of the instantaneous type, providing additional control options. The LC1DT60A3FD is capable of withstanding rated impulse voltages up to 6 kV and has a mechanical durability of 6 million operations at no load. It supports a rated voltage of up to 690V AC phase-to-phase, making it suitable for a wide range of applications.

Schneider Electric LC1DT40UD is a magnetic contactor from the Deca sub-range, designed with screw connections and equipped with 4 poles (4NO). It has a rated current of 40A (AC-1) and is suitable for DIN rail mounting. The net width of the contactor is 45 mm, and it offers a degree of protection rated at IP20. The control voltage (DC) ranges from 187.5-312.5Vdc (250Vdc nominal; 0.75...1.25 x Uc), with a rated operating voltage (Ue) of 690 V. This model includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, both types being 1NO+1NC instantaneous auxiliaries. The rated impulse voltage (Uimp) is 6 kV, and it boasts a mechanical durability of 15,000,000 operations at no load. The rated voltage (AC) for phase-to-phase connections is also 690 V.

Schneider Electric LC1DT406F7 is a magnetic contactor from the Deca sub-range, designed with ring-lugs connections and equipped with 4 poles (4NO) for circuit control. It supports a rated current of 40A under AC-1 conditions and is suitable for DIN rail mounting. The contactor has a net width of 45 mm and offers a degree of protection rated at IP20. It operates within control voltage ranges of 88-121Vac at 50Hz and 93.5-121Vac at 60Hz, with a nominal control voltage of 110Vac. This model includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, both of the instantaneous type (1NO+1NC). It is designed to withstand a rated impulse voltage (Uimp) of 6 kV and offers a mechanical durability of up to 15 million operations at no load. The rated voltage for phase-to-phase connections is specified at 690 V AC.

Schneider Electric LC1DT32D7 is a magnetic contactor from the Deca sub-range, featuring screw connections and designed with 4 poles (4NO) for circuit control. It has a rated current of 32A (AC-1) and is suitable for DIN rail mounting. The compact unit has a net width of 45 mm and offers a degree of protection rated at IP20. The control voltage for AC ranges between 33.6-46.2Vac at 50Hz and 35.7-46.2Vac at 60Hz, with a nominal voltage of 42Vac. It operates at a rated operating voltage (Ue) of up to 690 V and includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, with the contacts type being 1NO+1NC instantaneous auxiliaries. The LC1DT32D7 is designed to withstand a rated impulse voltage (Uimp) of 6 kV and boasts a mechanical durability of 15 million operations at no load, ensuring its capability to handle phase-to-phase rated voltages up to 690 V.

Schneider Electric LC1DT323M7 is a magnetic contactor from the Deca sub-range, featuring spring connections and designed with 4 poles (4NO) for circuit control. It has a rated current of 32A (AC-1) and is suitable for DIN rail mounting. The dimensions include a net width of 45 mm, and it offers a degree of protection rated at IP20. The control voltage for AC ranges between 176-242Vac (220Vac nominal; 50Hz; 0.8...1.1 x Uc) and 187-242Vac (220Vac nominal; 60Hz; 0.85...1.1 x Uc). This contactor is equipped with 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, both types being instantaneous (1NO+1NC). It has a rated impulse voltage (Uimp) of 6 kV and a mechanical durability of 15,000,000 operations at no load. The rated voltage (AC) for phase-to-phase connections is up to 690 V.

Schneider Electric LC1D323Q7 is a magnetic contactor from the Deca sub-range, featuring spring connections and designed with 3 poles (3P; 3NO). It has a rated current of 50A for AC-1 and 32A for AC-3 at 440Vac, with a mounting mode suitable for DIN rail installation. The net width of the contactor is 45 mm, and it offers a degree of protection rated at IP20. The control voltage (AC) ranges from 304-418Vac at 50Hz and 323-418Vac at 60Hz, with a nominal voltage of 380Vac. The rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV, and the rated active power spans from 7.5kW at 220-230Vac to 18.5kW at 660-690Vac in AC-3. It also features 1 normally closed (NC) auxiliary contact with contacts type of 1NO+1NC instantaneous aux. The rated power (HP) varies from 2HP at 115Vac in single-phase to 25HP at 575-600Vac in three-phase, under UL/CSA standards. The mechanical durability of the LC1D323Q7 is up to 15 million operations at no load, and its electrical durability with load reaches 1.6 million operations. The rated voltage (AC) phase-to-phase is 690 V.

Schneider Electric LC1D323R7 is a magnetic contactor from the Deca sub-range, featuring spring connections and designed with 3 poles (3P; 3NO). It has a rated current of 50A for AC-1 and 32A for AC-3 at 440Vac. This contactor is suitable for DIN rail mounting and has a net width of 45 mm. It offers a degree of protection rated at IP20 and operates with a control voltage (AC) range of 352-484Vac at 50Hz and 374-484Vac at 60Hz, with a nominal voltage of 440Vac. The rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV. Its rated active power reaches up to 18.5kW for AC-3 across various voltages, and it also features 1 normally closed (NC) auxiliary contact with a contact type of 1NO+1NC instantaneous aux. The rated power in horsepower (HP) varies from 2HP at 115Vac to 25HP at 575-600Vac, accommodating both single-phase and 3-phase connections. The mechanical durability of the LC1D323R7 is rated at 15 million operations, and its electrical durability with load is 1.6 million operations. The rated voltage for phase-to-phase connections is 690 V.
