Contactors

Schneider Electric LC1D40AJ5 is a magnetic contactor from the Deca sub-range featuring EverLink(TM) terminal design and screw connections. It is a 3-pole (3P; 3NO) contactor with a rated current of 60A for AC-1 and 40A for 440Vac in AC-3. Designed for DIN rail mounting, it has a net width of 55 mm and offers a degree of protection of IP20. The control voltage (AC) ranges from 9.6-13.2Vac (12Vac nominal; 50Hz; 0.8...1.1 x Uc). Its rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV. The rated active power spans from 11kW at 220-230Vac to 30kW at 660-690Vac in AC-3. It also features 1 normally closed (NC) auxiliary contact with a contact type of 1NO+1NC instantaneous aux. The rated power in horsepower (HP) varies from 3HP at 115Vac in single-phase to 30HP at 575-600Vac in 3-phase, according to UL/CSA standards. Its mechanical durability is rated at 6,000,000 operations, and its electrical durability with load is 1,500,000 operations. The rated voltage (AC) phase-to-phase is 690 V.

Schneider Electric LC1D40AFD is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminal design and screw connections. This 3-pole (3P; 3NO) contactor supports a rated current of 60A for AC-1 and 40A for AC-3 at 440Vac. It is designed for DIN rail mounting and has a net width of 55 mm. The LC1D40AFD offers a degree of protection of IP20 and operates with a control voltage (DC) range of 82.5-137.5Vdc (110Vdc nominal; 0.75...1.25 x Uc). Its rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. This contactor can handle rated active power ranging from 11kW at 220-230Vac to 30kW at 660-690Vac in AC-3. It also supports rated power in horsepower (HP) for various voltages and phases under UL/CSA standards. The mechanical durability of the LC1D40AFD is rated at 6 million operations at no load, and its electrical durability is rated at 1.5 million operations with load. The rated voltage (AC) for phase-to-phase connections is 690 V.

Schneider Electric LC1D40ACD is a magnetic contactor from the Deca sub-range, featuring an EverLink(TM) terminal design and screw connections. It is a 3-pole (3P; 3NO) device with a rated current of 60A (AC-1) and 40A (440Vac; AC-3). This contactor is designed for DIN rail mounting and has a net width of 55 mm. It offers a degree of protection of IP20 and operates with a control voltage (DC) of 27-45Vdc (36Vdc nom.; 0.75...1.25 x Uc). The rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV. Its rated active power ranges from 11kW at 220-230Vac to 30kW at 660-690Vac in AC-3 category. It also features 1 normally closed (NC) auxiliary contact with contacts type of 1NO+1NC instantaneous aux. The rated power in horsepower (HP) varies from 3HP at 115Vac to 30HP at 575-600Vac, covering both single-phase and 3-phase applications. The mechanical durability of the LC1D40ACD is rated at 6,000,000 operations, and its electrical durability with load is 1,500,000 operations. The rated voltage (AC) for phase-to-phase applications is 690 V.

Schneider Electric LC1D40A6Q7 is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminals and ring-lugs connections. This 3-pole (3P; 3NO) contactor is designed for DIN rail mounting and has a net width of 55 mm. It offers a degree of protection of IP20 and operates with a control voltage (AC) of 304-418Vac (380Vac nominal; 50Hz; 0.8...1.1 x Uc) and 323-418Vac (380Vac nominal; 60Hz; 0.85...1.1 x Uc). The rated operating voltage (Ue) is 690 V, and it includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated current is 60A (AC-1) and 40A (440Vac; AC-3), with a rated impulse voltage (Uimp) of 6 kV. It supports rated active power of 11kW (220-230Vac; AC-3) up to 30kW (660-690Vac; AC-3) and rated power (HP) ranging from 3HP (115Vac; single-phase) to 30HP (575-600Vac; 3-phase), according to UL/CSA standards. The mechanical durability is rated at 6,000,000 operations, and electrical durability at 1,500,000 operations with load. The rated voltage (AC) phase-to-phase is 690 V.

Schneider Electric LC1D40A6FE7 is a magnetic contactor from the Deca sub-range featuring EverLink(TM) terminals and ring-lugs connections. This 3-pole (3P; 3NO) contactor is designed for DIN rail mounting and has a net width of 55 mm. It offers a degree of protection of IP20 and operates with a control voltage (AC) of 92-126Vac (115Vac nominal; 50Hz; 0.8...1.1 x Uc) and 98-126Vac (115Vac nominal; 60Hz; 0.85...1.1 x Uc). The rated operating voltage (Ue) is 690 V, and it comes with 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated current is 60A (AC-1) and 40A (440Vac; AC-3), with a rated impulse voltage (Uimp) of 6 kV. It supports rated active power of 11kW (220-230Vac; AC-3) up to 30kW (660-690Vac; AC-3) and rated power (HP) ranging from 3HP (115Vac; single-phase; 50Hz/60Hz; UL/CSA) to 30HP (575-600Vac; 3-phase; 50Hz/60Hz; UL/CSA). The mechanical durability is rated at 6,000,000 operations, and electrical durability (with load) at 1,500,000 operations. The rated voltage (AC) - phase-to-phase is 690 V.

Schneider Electric LC1D40A6FC7 is a magnetic contactor from the Deca sub-range, featuring an EverLink(TM) terminal design for ring-lugs connections. This 3-pole (3P; 3NO) contactor is designed for DIN rail mounting and has a net width of 55 mm. It offers a degree of protection of IP20 and operates with a control voltage (AC) range of 102-139Vac at 50Hz and 108-139Vac at 60Hz, with a nominal control voltage of 127Vac. The rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated current is 60A for AC-1 applications and 40A for 440Vac in AC-3 scenarios. It supports rated impulse voltage (Uimp) of 6 kV and rated active power ranging from 11kW at 220-230Vac to 30kW at 660-690Vac in AC-3. The rated power in horsepower (HP) varies from 3HP at 115Vac in single-phase to 30HP at 575-600Vac in three-phase applications, according to UL/CSA standards. The mechanical durability of the LC1D40A6FC7 is rated at 6 million operations at no load, and its electrical durability is rated at 1.5 million operations with load. The rated voltage (AC) for phase-to-phase applications is 690 V.

Schneider Electric LC1D40A6F7 is a magnetic contactor from the Deca sub-range, featuring an EverLink(TM) terminal design and ring-lugs connections. It is a 3-pole (3P; 3NO) contactor with a rated current of 60A (AC-1) and 40A (440Vac; AC-3). This contactor is designed for DIN rail mounting and has a net width of 55 mm. It offers a degree of protection of IP20 and operates with a control voltage (AC) of 88-121Vac (110Vac nom.; 50Hz; 0.8...1.1 x Uc) and 93.5-121Vac (110Vac nom.; 60Hz; 0.85...1.1 x Uc). The rated operating voltage (Ue) is 690 V, and it includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. It has a rated active power of 11kW (220-230Vac; AC-3) up to 30kW (660-690Vac; AC-3) and a rated power in horsepower ranging from 3HP (115Vac; single-phase) to 30HP (575-600Vac; 3-phase) under UL/CSA standards. The mechanical durability of the LC1D40A6F7 is rated at 6,000,000 operations, and its electrical durability (with load) is 1,500,000 operations. The rated voltage (AC) phase-to-phase is 690 V.

Schneider Electric LC1D40A6ED is a magnetic contactor from the Deca sub-range featuring EverLink(TM) terminal design and ring-lugs connections. This 3-pole (3P; 3NO) contactor has a rated current of 60A for AC-1 and 40A for 440Vac in AC-3 applications. It is designed for DIN rail mounting and has a net width of 55 mm. The degree of protection provided is IP20, and it operates with a control voltage (DC) range of 36-60Vdc, nominally at 48Vdc. The rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV. Its rated active power ranges from 11kW at 220-230Vac to 30kW at 660-690Vac in AC-3. It also features 1 normally closed (NC) auxiliary contact with contacts type of 1NO+1NC instantaneous aux. The rated power in horsepower (HP) varies from 3HP at 115Vac in single-phase to 30HP at 575-600Vac in three-phase applications, according to UL/CSA standards. The mechanical durability of the LC1D40A6ED is rated at 6 million operations at no load, and its electrical durability with load is 1.5 million operations. The rated voltage (AC) phase-to-phase is 690 V.

Schneider Electric LC1D40A3UD is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminal design for secure connections. It is equipped with spring connections for control and screw connections for power, and operates with 3 poles (3P; 3NO). This contactor is designed for a rated current of 60A under AC-1 conditions and 40A at 440Vac under AC-3 conditions. It supports DIN rail mounting and has a net width of 55 mm. The LC1D40A3UD offers an IP20 degree of protection and operates with a control voltage range of 187.5-312.5Vdc (250Vdc nominal; 0.75...1.25 x Uc). Its rated operating voltage (Ue) reaches up to 690 V, and it includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV. This contactor can handle rated active power ranging from 11kW at 220-230Vac to 30kW at 660-690Vac under AC-3 conditions. It also features 1 normally closed (NC) auxiliary contact and instantaneous auxiliary contacts type of 1NO+1NC. The rated power in horsepower varies from 3HP at 115Vac to 30HP at 575-600Vac, suitable for both single-phase and 3-phase systems under UL/CSA standards. Its mechanical durability is rated at 6,000,000 operations, and its electrical durability with load is 1,500,000 operations. The rated voltage for phase-to-phase is 690 V.

Schneider Electric LC1D40A3U7 is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminal design for secure connections. It is equipped with spring connections for control and screw connections for power, supporting a 3-pole (3P; 3NO) configuration. The contactor is rated for 60A under AC-1 conditions and 40A at 440Vac under AC-3 conditions. It is designed for DIN rail mounting and has a net width of 55 mm. The device offers an IP20 degree of protection and operates with a control voltage of 192-264Vac at 50Hz or 204-264Vac at 60Hz. The rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. It can handle rated active power ranging from 11kW at 220-230Vac to 30kW at 660-690Vac under AC-3 conditions. The rated power in horsepower (HP) varies from 3HP at 115Vac in single-phase to 30HP at 575-600Vac in three-phase, according to UL/CSA standards. The mechanical durability of the contactor is rated at 6 million operations at no load, and its electrical durability is rated at 1.5 million operations with load. The rated voltage for phase-to-phase connections is 690 V.
