AC/DC Power Supplies
AC/DC power supplies are power supplies that convert alternating current from the grid into direct current that is needed to power most electronics. AC/DC power supplies are integral components in systems that make the world go round.
PULS ML95.100 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and is designed according to NEC Class 2 standards. This unit offers a rated current of 3.9A at 24Vdc and features spring-clamp connections for ease of installation. It supports a wide supply voltage range, accepting AC inputs from 85Vac to 132Vac or 184Vac to 264Vac (auto-select based on 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, 240Vac nominal; 47-63Hz) and DC inputs from 213Vdc to 377Vdc (220Vdc, 250Vdc nominal). The ML95.100 is housed in a PC / ABS blend, measuring 73mm in width, 75mm in height, and 103mm in depth. It is suitable for single-phase (1AC) or DC networks, with a rated power of 95W and an adjustable output voltage range of 24Vdc to 28Vdc. It includes protection functions such as NTC for input inrush current limiting, achieves an efficiency of 0.9 with a 230Vac input, and has a maximum inrush current consumption of 22A at 120Vac input and 37A peak at 230Vac input. Power dissipation/losses are rated at 10.5W, and it features a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω.
Quick Quote
PULS QS10.241-C1 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and is equipped with a conformal coating for enhanced durability in harsh environments. The unit provides a rated current of 10A at 24Vdc and 9A at 28Vdc, with spring-clamp connections for secure wiring. It supports a supply voltage range of 85Vac-264Vac for AC and 88Vdc-188Vdc for DC, with specific turn-on and shutdown voltages detailed for various conditions. The QS10.241-C1, part of the Q-series, measures 60mm in width, 124mm in height, and 117mm in depth, housed in an aluminium casing. It is compatible with single-phase AC or DC networks and offers a rated power of 240W at 24V and 252W at 28V, with a short-term capacity of 360W for up to 4 seconds. The output voltage is adjustable between 24Vdc and 28Vdc, featuring overvoltage protection and capabilities for parallel operation to increase output power. Efficiency rates vary with input voltage, and the unit showcases specific current consumption, time delay, hold time, power dissipation, and electrical durability metrics. Ripple is maintained at 50mVpp, and the output stage capacitance is 7000µF.
Quick Quote
PULS QS40.244 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 40A at 24Vdc and 34.3A at 28Vdc, with screw-clamp connections for secure installation. It supports a supply voltage range of 180Vac to 264Vac across various nominal values and frequencies, with specific turn-ON and shutdown voltages. As part of the Q-series, it measures 125mm in width, 124mm in height, and 127mm in depth, housed in an aluminium casing. This single-phase unit delivers a rated power of 960W, with a short-term capacity of 1440W for up to 4 seconds, and an adjustable output voltage between 24Vdc and 28Vdc. It features comprehensive protection functions, including output overvoltage protection and overload/short-circuit current management, and is capable of series or parallel operation for increased output power. The QS40.244 maintains efficiency at 0.946 with a 230Vac input and incorporates a time delay for start-up and rise, alongside a hold time of 30ms at 230Vac input. Power dissipation is noted at 54.8W under full output load with a 230Vac input. Its electrical durability spans up to 311,000 hours at 25°C with a 20A output, and it exhibits a ripple of 100mVpp across a 20Hz to 20MHz range with a 50Ω load. The output stage capacitance is 10200µF, ensuring stable performance across its operational lifespan.
Quick Quote
PULS QT20.481 is a power supply unit designed for AC/DC conversion with a 50% power reserve, suitable for DIN rail mounting. It operates within an ambient air temperature range of -25 to +70°C and features a design that includes a DC-OK relay contact output. The unit provides a rated current of 10A at 48Vdc and 8.7A at 55Vdc, with a power derating applicable from 12W at +60°C to +70°C. Connection is facilitated through spring-clamp connections. It supports a wide range supply voltage from 323Vac to 576Vac across various nominal voltages (380Vac / 400Vac / 415Vac / 440Vac / 480Vac / 500Vac / 525Vac) at 47-63Hz, indicating a 3-phase input capability with specific turn-ON and shutdown voltages. The QT20.481, part of the Q-series, measures 65mm in width, 124mm in height, and 127mm in depth, housed in aluminium for durability. It is designed for a 3-phase network, with a rated power of 480W at both 48Vdc and 55Vdc, and can momentarily support up to 720W for short durations (4s). The output voltage is adjustable between 48Vdc and 55Vdc. Protection features include output overvoltage protection and active input inrush current limiting, with capabilities for overload/short-circuit protection, series/parallel operation, and back-feeding load resistance. Efficiency rates are high, at 0.95 for a 3x480Vac input and 0.954 for a 3x400Vac input. The unit exhibits a peak current consumption of 10A at both 3x400Vac and 3x480Vac inputs, with specific start-up delay and rise times. Hold time is consistent at 22ms for both 3x480Vac and 3x400Vac inputs. Power dissipation varies with input voltage, and the unit's electrical durability is rated in hours across different conditions. Ripple is maintained at 100mVpp across a 20Hz to 20MHz range, with an output stage capacitance of 250µF.
Quick Quote
PULS SLA8.100 is a power supply unit designed with a DC-OK relay contact output and functions as an AS-Interface PSU. It is encased in a robust metal housing and utilizes screw-clamp connections for secure installation. The dimensions of this unit are W91mm x H124mm x D102mm. It supports a wide range of supply voltages, including AC inputs from 85Vac to 132Vac and 187Vac to 264Vac, as well as DC inputs from 230Vdc to 375Vdc, with manual selection available for specific nominal voltages. The rated current is 8A at 30.6Vdc, with a derating at 6W/+60°C to +70°C. Designed for DIN rail mounting, it operates efficiently within an ambient air temperature range of -10 to +70 °C. The SLA8.100 experiences a peak inrush current consumption of 27A at 240Vac input and 14A at 120Vac input. It is compatible with single-phase (1AC) or DC networks and incorporates protection functions against output overvoltage (up to 55Vdc max.), with an active input inrush current limiter and overload/short-circuit protection ranging from min. 12A to max. 25A. However, series or parallel operation is not supported. The output voltage is fixed at 30.6Vdc, with an efficiency of 0.92 at 230Vac input. The hold time is 10ms at 100Vac input, with power dissipation/losses at 21.2W under full output load at 230Vac input. Ripple is maintained at 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω.
Quick Quote
PULS XT40.481 is a power supply unit part of the X-series, designed to function as an AC/DC PSU/converter with a semi-regulated 25% power reserve and a DC-OK relay contact output. It operates on a supply voltage of 3x360-440Vac (380Vac / 400Vac / 415Vac nominal; 47-63Hz), with a turn-ON voltage of 3 x 325Vac and a shutdown voltage of 3 x 295Vac. The unit is housed in aluminium, featuring screw-clamp connections for secure installation and is designed for DIN rail mounting. It supports a 3-phase (3AC) network type and can operate within an ambient air temperature range of -25 to +70°C. The XT40.481 has a net width of 96mm and dimensions of W96mm x H124mm x D159mm. It is rated for a current of 20A at 48Vdc, with a peak inrush current consumption of 4A (at 3x400Vac input). The rated power is 960W at 48Vdc, with a derating to 24W between +60°C and +70°C, and can momentarily support up to 1200W for approximately 15 seconds. Protection features include output overvoltage protection (57.2Vdc max.), active input inrush current limiter, and overload/short-circuit current protection, typically 90A at load impedance. It is not designed for series or parallel operation to increase output power but supports 1+1 redundancy for higher system reliability. The unit is resistant to back-feeding loads up to 55.1V. It boasts an efficiency of 0.96 (at 3x400Vac input), with a 400ms start-up delay, a rise time of 40ms (at nominal input with 0mF load capacitance) to 70ms (with 20mF load capacitance), and a fixed output voltage of 48Vdc with a 1V turn-ON overshoot. The hold time is 3.1ms at 3x400Vdc input, with power dissipation/losses at 40W (full output load). Its electrical durability is rated at 77000 hours (at 40°C; 20A output; 3AC 400Vdc input) to 15 years / 131400 hours (at 25°C; 20A output; 3AC 400Vdc input). The output stage capacitance is 7600µF, with a ripple of 2500mVpp (20Hz...2KHz; 50Ω).
Quick Quote
PULS XT40.721 is a power supply unit part of the X-series, designed to function as an AC/DC PSU/converter with a semi-regulated 25% power reserve and a DC-OK relay contact output. It operates on a supply voltage of 3x360-440Vac (with nominal values of 380Vac, 400Vac, 415Vac; 47-63Hz), featuring a turn-ON voltage of 3 x 325Vac and a shutdown voltage of 3 x 295Vac. The unit is encased in an aluminium housing, measures W96mm x H124mm x D159mm, and uses screw-clamp connections for installation. It is rated for a current of 13.3A at 72Vdc and is designed for DIN rail mounting in a 3-phase (3AC) network. The XT40.721 can operate in ambient air temperatures ranging from -25 to +70°C. It has a peak inrush current consumption of 4A (at 3x400Vac input), a rated power of 24W/+60°C...+70°C (derating) to 960W (at 72Vdc) and 1200W for typical 15s. Protection features include output overvoltage protection (91.1Vdc max.), active input inrush current limiter, and overload/short-circuit current protection. It supports series operation but not parallel operation for increased output power, though 1+1 redundancy for higher system availability and reliability is possible. The unit is resistant to back-feeding loads up to 87.9V. It boasts an efficiency of 0.955 (with 3x400Vac input), a 400ms start-up delay, and a rise time of 40ms to 70ms depending on load capacitance. The output voltage is fixed at 72Vdc with a 1.4V turn-ON overshoot, a hold time of 3.6ms at 3x400Vdc input, power dissipation/losses of 45.2W (at 3x400Vdc input; full output load), an output stage capacitance of 4050 µF, and a ripple of 3000mVpp (20Hz...2KHz; 50Ω).
Quick Quote
Power Supply, IP65/67, 500W, AC 380-480V input, 3 phase, 24-28Vdc output, 20.8A, HAN Q4/2, ASi Cable
Quick Quote
PULS CP5.121 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing and dimensions of W32mm x H124mm x D102mm. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32 mm. The unit offers a current consumption of 7A peak max inrush at both 230Vac and 120Vac inputs. Its efficiency rates are 0.94 at 230Vac input, 0.932 at 120Vac input, and 0.926 at 100Vac input. The CP5.121 provides a time delay of 350-400ms for start-up and a rise time of 30ms under nominal input with a constant full current load without load capacitance, and 50ms with 10mF load capacitance. It includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. The unit is resistant to back-feeding loads up to 25V. Power dissipation/losses are 7.7W at full output load with 230Vac input and 8.8W with 120Vac input. The output stage capacitance is 2700 µF. Electrical durability varies with conditions, offering up to 839000 hours at 25°C with 5A output and 1AC 120Vac input. The ripple is 50mVpp across 20Hz to 20MHz at 50Ω. This AC/DC power supply unit, part of the CP-series, is designed with a 20% power reserve, DC-OK relay contact output, and screw-clamp connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-150Vdc for DC, with a rated current of 10A at 12Vdc, and provides an adjustable output voltage of 12Vdc-15Vdc. The hold time is 35ms at both 120/230Vac input.
Quick Quote
PULS CP10.241-M1 is a DIN rail mounting power supply unit with an aluminium housing, designed for a net width of 39 mm. It operates within an ambient air temperature range of -25 to +70°C and features a current consumption of 11A peak max. inrush at 230Vac input and 7A peak max. inrush at 120Vac input. The efficiency rates are 0.952 at 230Vac input, 0.936 at 120Vac input, and 0.929 at 100Vac input. Its dimensions are W39mm x H124mm x D117mm. The unit has a start-up delay of 240-300ms for 100-230Vac input, with a rise time of 30ms under nominal input at constant full current load with 0mF load capacitance, and 75ms with 10mF load capacitance. It includes protection functions such as output overvoltage protection and overload/short-circuit current protection, with specific resistance to back-feeding loads up to 35V. Power dissipation/losses are 12.1 W at 230Vac input with full output load and 16.4 W at 120Vac input with full output load. The output stage capacitance is 4400 µF. Electrical durability varies with conditions, reaching up to 499000 hours at 25°C with 5A output and 1AC 230Vac input. The ripple is 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit, part of the CP-series designed for medical applications, features a DC-OK relay contact output and spring-clamp connections. It supports a supply voltage range of 85Vac-264Vac for various nominal inputs and 264-300Vac input overvoltage for up to 500ms. The rated current is 10A at 24Vdc with a derating from 6W/+60°C to +70°C. It is suitable for single-phase networks, offers a rated power of 240W, and provides an adjustable output voltage of 24Vdc-28Vdc with a 200mV turn-ON overshoot. The hold time is 37ms.
Quick Quote
| Item | Manufacturer | Price | Stock | Delivery | |
|---|---|---|---|---|---|
| ML95.100 PULS ML95.100 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and is designed according to NEC Class 2 standards. This unit offers a rated current of 3.9A at 24Vdc and features spring-clamp connections for ease of installation. It supports a wide supply voltage range, accepting AC inputs from 85Vac to 132Vac or 184Vac to 264Vac (auto-select based on 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, 240Vac nominal; 47-63Hz) and DC inputs from 213Vdc to 377Vdc (220Vdc, 250Vdc nominal). The ML95.100 is housed in a PC / ABS blend, measuring 73mm in width, 75mm in height, and 103mm in depth. It is suitable for single-phase (1AC) or DC networks, with a rated power of 95W and an adjustable output voltage range of 24Vdc to 28Vdc. It includes protection functions such as NTC for input inrush current limiting, achieves an efficiency of 0.9 with a 230Vac input, and has a maximum inrush current consumption of 22A at 120Vac input and 37A peak at 230Vac input. Power dissipation/losses are rated at 10.5W, and it features a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω. | Puls | $294.00 | Quick Quote | |
| QS10.241-C1 PULS QS10.241-C1 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and is equipped with a conformal coating for enhanced durability in harsh environments. The unit provides a rated current of 10A at 24Vdc and 9A at 28Vdc, with spring-clamp connections for secure wiring. It supports a supply voltage range of 85Vac-264Vac for AC and 88Vdc-188Vdc for DC, with specific turn-on and shutdown voltages detailed for various conditions. The QS10.241-C1, part of the Q-series, measures 60mm in width, 124mm in height, and 117mm in depth, housed in an aluminium casing. It is compatible with single-phase AC or DC networks and offers a rated power of 240W at 24V and 252W at 28V, with a short-term capacity of 360W for up to 4 seconds. The output voltage is adjustable between 24Vdc and 28Vdc, featuring overvoltage protection and capabilities for parallel operation to increase output power. Efficiency rates vary with input voltage, and the unit showcases specific current consumption, time delay, hold time, power dissipation, and electrical durability metrics. Ripple is maintained at 50mVpp, and the output stage capacitance is 7000µF. | Puls | $635.00 | Quick Quote | |
| QS40.244 PULS QS40.244 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 40A at 24Vdc and 34.3A at 28Vdc, with screw-clamp connections for secure installation. It supports a supply voltage range of 180Vac to 264Vac across various nominal values and frequencies, with specific turn-ON and shutdown voltages. As part of the Q-series, it measures 125mm in width, 124mm in height, and 127mm in depth, housed in an aluminium casing. This single-phase unit delivers a rated power of 960W, with a short-term capacity of 1440W for up to 4 seconds, and an adjustable output voltage between 24Vdc and 28Vdc. It features comprehensive protection functions, including output overvoltage protection and overload/short-circuit current management, and is capable of series or parallel operation for increased output power. The QS40.244 maintains efficiency at 0.946 with a 230Vac input and incorporates a time delay for start-up and rise, alongside a hold time of 30ms at 230Vac input. Power dissipation is noted at 54.8W under full output load with a 230Vac input. Its electrical durability spans up to 311,000 hours at 25°C with a 20A output, and it exhibits a ripple of 100mVpp across a 20Hz to 20MHz range with a 50Ω load. The output stage capacitance is 10200µF, ensuring stable performance across its operational lifespan. | Puls | $1,005.00 | Quick Quote | |
| QT20.481 PULS QT20.481 is a power supply unit designed for AC/DC conversion with a 50% power reserve, suitable for DIN rail mounting. It operates within an ambient air temperature range of -25 to +70°C and features a design that includes a DC-OK relay contact output. The unit provides a rated current of 10A at 48Vdc and 8.7A at 55Vdc, with a power derating applicable from 12W at +60°C to +70°C. Connection is facilitated through spring-clamp connections. It supports a wide range supply voltage from 323Vac to 576Vac across various nominal voltages (380Vac / 400Vac / 415Vac / 440Vac / 480Vac / 500Vac / 525Vac) at 47-63Hz, indicating a 3-phase input capability with specific turn-ON and shutdown voltages. The QT20.481, part of the Q-series, measures 65mm in width, 124mm in height, and 127mm in depth, housed in aluminium for durability. It is designed for a 3-phase network, with a rated power of 480W at both 48Vdc and 55Vdc, and can momentarily support up to 720W for short durations (4s). The output voltage is adjustable between 48Vdc and 55Vdc. Protection features include output overvoltage protection and active input inrush current limiting, with capabilities for overload/short-circuit protection, series/parallel operation, and back-feeding load resistance. Efficiency rates are high, at 0.95 for a 3x480Vac input and 0.954 for a 3x400Vac input. The unit exhibits a peak current consumption of 10A at both 3x400Vac and 3x480Vac inputs, with specific start-up delay and rise times. Hold time is consistent at 22ms for both 3x480Vac and 3x400Vac inputs. Power dissipation varies with input voltage, and the unit's electrical durability is rated in hours across different conditions. Ripple is maintained at 100mVpp across a 20Hz to 20MHz range, with an output stage capacitance of 250µF. | Puls | $780.00 | Quick Quote | |
| SLA8.100 PULS SLA8.100 is a power supply unit designed with a DC-OK relay contact output and functions as an AS-Interface PSU. It is encased in a robust metal housing and utilizes screw-clamp connections for secure installation. The dimensions of this unit are W91mm x H124mm x D102mm. It supports a wide range of supply voltages, including AC inputs from 85Vac to 132Vac and 187Vac to 264Vac, as well as DC inputs from 230Vdc to 375Vdc, with manual selection available for specific nominal voltages. The rated current is 8A at 30.6Vdc, with a derating at 6W/+60°C to +70°C. Designed for DIN rail mounting, it operates efficiently within an ambient air temperature range of -10 to +70 °C. The SLA8.100 experiences a peak inrush current consumption of 27A at 240Vac input and 14A at 120Vac input. It is compatible with single-phase (1AC) or DC networks and incorporates protection functions against output overvoltage (up to 55Vdc max.), with an active input inrush current limiter and overload/short-circuit protection ranging from min. 12A to max. 25A. However, series or parallel operation is not supported. The output voltage is fixed at 30.6Vdc, with an efficiency of 0.92 at 230Vac input. The hold time is 10ms at 100Vac input, with power dissipation/losses at 21.2W under full output load at 230Vac input. Ripple is maintained at 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω. | Puls | $1,025.00 | Quick Quote | |
| XT40.481 PULS XT40.481 is a power supply unit part of the X-series, designed to function as an AC/DC PSU/converter with a semi-regulated 25% power reserve and a DC-OK relay contact output. It operates on a supply voltage of 3x360-440Vac (380Vac / 400Vac / 415Vac nominal; 47-63Hz), with a turn-ON voltage of 3 x 325Vac and a shutdown voltage of 3 x 295Vac. The unit is housed in aluminium, featuring screw-clamp connections for secure installation and is designed for DIN rail mounting. It supports a 3-phase (3AC) network type and can operate within an ambient air temperature range of -25 to +70°C. The XT40.481 has a net width of 96mm and dimensions of W96mm x H124mm x D159mm. It is rated for a current of 20A at 48Vdc, with a peak inrush current consumption of 4A (at 3x400Vac input). The rated power is 960W at 48Vdc, with a derating to 24W between +60°C and +70°C, and can momentarily support up to 1200W for approximately 15 seconds. Protection features include output overvoltage protection (57.2Vdc max.), active input inrush current limiter, and overload/short-circuit current protection, typically 90A at load impedance. It is not designed for series or parallel operation to increase output power but supports 1+1 redundancy for higher system reliability. The unit is resistant to back-feeding loads up to 55.1V. It boasts an efficiency of 0.96 (at 3x400Vac input), with a 400ms start-up delay, a rise time of 40ms (at nominal input with 0mF load capacitance) to 70ms (with 20mF load capacitance), and a fixed output voltage of 48Vdc with a 1V turn-ON overshoot. The hold time is 3.1ms at 3x400Vdc input, with power dissipation/losses at 40W (full output load). Its electrical durability is rated at 77000 hours (at 40°C; 20A output; 3AC 400Vdc input) to 15 years / 131400 hours (at 25°C; 20A output; 3AC 400Vdc input). The output stage capacitance is 7600µF, with a ripple of 2500mVpp (20Hz...2KHz; 50Ω). | Puls | $790.00 | Quick Quote | |
| XT40.721 PULS XT40.721 is a power supply unit part of the X-series, designed to function as an AC/DC PSU/converter with a semi-regulated 25% power reserve and a DC-OK relay contact output. It operates on a supply voltage of 3x360-440Vac (with nominal values of 380Vac, 400Vac, 415Vac; 47-63Hz), featuring a turn-ON voltage of 3 x 325Vac and a shutdown voltage of 3 x 295Vac. The unit is encased in an aluminium housing, measures W96mm x H124mm x D159mm, and uses screw-clamp connections for installation. It is rated for a current of 13.3A at 72Vdc and is designed for DIN rail mounting in a 3-phase (3AC) network. The XT40.721 can operate in ambient air temperatures ranging from -25 to +70°C. It has a peak inrush current consumption of 4A (at 3x400Vac input), a rated power of 24W/+60°C...+70°C (derating) to 960W (at 72Vdc) and 1200W for typical 15s. Protection features include output overvoltage protection (91.1Vdc max.), active input inrush current limiter, and overload/short-circuit current protection. It supports series operation but not parallel operation for increased output power, though 1+1 redundancy for higher system availability and reliability is possible. The unit is resistant to back-feeding loads up to 87.9V. It boasts an efficiency of 0.955 (with 3x400Vac input), a 400ms start-up delay, and a rise time of 40ms to 70ms depending on load capacitance. The output voltage is fixed at 72Vdc with a 1.4V turn-ON overshoot, a hold time of 3.6ms at 3x400Vdc input, power dissipation/losses of 45.2W (at 3x400Vdc input; full output load), an output stage capacitance of 4050 µF, and a ripple of 3000mVpp (20Hz...2KHz; 50Ω). | Puls | $910.00 | Quick Quote | |
| FPT500.241-006-104 Power Supply, IP65/67, 500W, AC 380-480V input, 3 phase, 24-28Vdc output, 20.8A, HAN Q4/2, ASi Cable | Puls | $1,000.00 | Quick Quote | |
| CP5.121 PULS CP5.121 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing and dimensions of W32mm x H124mm x D102mm. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32 mm. The unit offers a current consumption of 7A peak max inrush at both 230Vac and 120Vac inputs. Its efficiency rates are 0.94 at 230Vac input, 0.932 at 120Vac input, and 0.926 at 100Vac input. The CP5.121 provides a time delay of 350-400ms for start-up and a rise time of 30ms under nominal input with a constant full current load without load capacitance, and 50ms with 10mF load capacitance. It includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. The unit is resistant to back-feeding loads up to 25V. Power dissipation/losses are 7.7W at full output load with 230Vac input and 8.8W with 120Vac input. The output stage capacitance is 2700 µF. Electrical durability varies with conditions, offering up to 839000 hours at 25°C with 5A output and 1AC 120Vac input. The ripple is 50mVpp across 20Hz to 20MHz at 50Ω. This AC/DC power supply unit, part of the CP-series, is designed with a 20% power reserve, DC-OK relay contact output, and screw-clamp connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-150Vdc for DC, with a rated current of 10A at 12Vdc, and provides an adjustable output voltage of 12Vdc-15Vdc. The hold time is 35ms at both 120/230Vac input. | Puls | $290.00 | Quick Quote | |
| CP10.241-M1 PULS CP10.241-M1 is a DIN rail mounting power supply unit with an aluminium housing, designed for a net width of 39 mm. It operates within an ambient air temperature range of -25 to +70°C and features a current consumption of 11A peak max. inrush at 230Vac input and 7A peak max. inrush at 120Vac input. The efficiency rates are 0.952 at 230Vac input, 0.936 at 120Vac input, and 0.929 at 100Vac input. Its dimensions are W39mm x H124mm x D117mm. The unit has a start-up delay of 240-300ms for 100-230Vac input, with a rise time of 30ms under nominal input at constant full current load with 0mF load capacitance, and 75ms with 10mF load capacitance. It includes protection functions such as output overvoltage protection and overload/short-circuit current protection, with specific resistance to back-feeding loads up to 35V. Power dissipation/losses are 12.1 W at 230Vac input with full output load and 16.4 W at 120Vac input with full output load. The output stage capacitance is 4400 µF. Electrical durability varies with conditions, reaching up to 499000 hours at 25°C with 5A output and 1AC 230Vac input. The ripple is 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit, part of the CP-series designed for medical applications, features a DC-OK relay contact output and spring-clamp connections. It supports a supply voltage range of 85Vac-264Vac for various nominal inputs and 264-300Vac input overvoltage for up to 500ms. The rated current is 10A at 24Vdc with a derating from 6W/+60°C to +70°C. It is suitable for single-phase networks, offers a rated power of 240W, and provides an adjustable output voltage of 24Vdc-28Vdc with a 200mV turn-ON overshoot. The hold time is 37ms. | Puls | $400.00 | Quick Quote | |
