25018EG3G449T-W22 WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 460 V
- Output Rating 250 HP
- Rated Speed 1785 rpm
- Flange Type Without
- Flange Without
- Output rating 250 HP
- Terminal box¹ Left position
- Synchronous speed 1800 rpm
- Approx. weight³ 2885 lb
- Number of poles 4
- Voltage 460 V
- Standard NEMA MG-1
- Noise level² 75.0 dB(A)
- Rotation¹ Both (CW and CCW)
- Starting Method Direct On Line
- Degree of Protection IP55
- Enclosure IC411 - TEFC
- Ambient temperature -20°C to +40°C
- Altitude 1000 m.a.s.l.
- Mounting F-1
- Service factor 1.25
- Duty Cycle Cont.(S1)
- Insulation Class F
- Design A
- Temperature rise 80 K
- Locked rotor time 37s (cold) 21s (hot)
- Breakdown torque 290 %
- Locked rotor torque 270 %
- Moment of inertia (J) 104 sq.ft.lb
- Rated current 286 A
- Rated torque 735 ft.lb
- Number of Poles 4
- No load current 100 A
- LRC 8.2x(Code J)
- L. R. Amperes 2345 A
- Rated voltage 460 V
- Slip 0.83 %
- Output 250 HP (185 kW)
- Frame 447/9T
- Frequency 60 Hz
- Rated speed 1785 rpm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
