20018OT3G445TC-W40 WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 460 V
- Output Rating 200 HP
- Rated Speed 1783 rpm
- Flange Type C
- Synchronous speed 1800 rpm
- Terminal box¹ Left position
- Flange C
- Output rating 200 HP
- Standard NEMA MG-1
- Number of poles 4
- Approx. weight³ 1460 lb
- Voltage 460//380 V
- Enclosure IC01 - ODP
- Rotation¹ Both (CW and CCW)
- Noise level² 78.0 dB(A)
- Mounting F-1
- Ambient temperature -20°C to +40°C
- Degree of Protection IP23
- Design B
- Altitude 1000 m.a.s.l.
- Temperature rise 80 K
- Starting Method Direct On Line
- Service factor 1.15
- Duty Cycle Cont.(S1)
- Locked rotor torque 210 %
- Insulation Class F
- Locked rotor time 25s (cold) 14s (hot)
- Rated torque 589 ft.lb
- Moment of inertia (J) 46.4 sq.ft.lb
- Breakdown torque 250 %
- Frequency 60 Hz
- No load current 86.5 A
- LRC 6.6x(Code G)
- Slip 0.94 %
- Rated voltage 460 V
- Frame 444/5TC
- Rated current 234 A
- Number of Poles 4
- Output 200 HP (150 kW)
- Rated speed 1783 rpm
- L. R. Amperes 1544 A
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
