12536OT3G404TS-RFVFD WEG AC Motors

Product Details

• Number of Poles
  2 Pole
• Voltage
  380 V
• Output Rating
  125 HP
• Rated Speed
  2962 rpm
• Flange Type
  Without
• Synchronous speed
  3600 rpm
• Standard
  NEMA MG-1
• Flange
  Without
• Voltage
  460//380 V
• Terminal box¹
  Left position
• Number of poles
  2
• Output rating
  125 HP
• Noise level²
  84.0 dB(A)
• Approx. weight³
  1010 lb
• Rotation¹
  Both (CW and CCW)
• Enclosure
  IC01 - ODP
• Starting Method
  VFD
• Duty Cycle
  Cont.(S1)
• Mounting
  F-1
• Ambient temperature
  -20°C to +40°C
Degree of Protection
IP23
Service factor
1.15
Temperature rise
105 K
Altitude
1000 m.a.s.l.
Insulation Class
F
Moment of inertia (J)
12.0 sq.ft.lb
Design
A
Locked rotor time
16s (cold) 9s (hot)
Breakdown torque
350 %
LRC
7.8x(Code H)
Locked rotor torque
350 %
Frame
404/5TS
Frequency
50 Hz
Rated torque
222 ft.lb
No load current
42.0 A
Rated voltage
380 V
Slip
1.27 %
Rated speed
2962 rpm
Rated current
163 A
L. R. Amperes
1271 A
Number of Poles
2
Output
125 HP
