00736EP3EPM213/5Y WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 230/460 V
- Output Rating 7.5 HP
- Rated Speed 3515 rpm
- Flange Type Without
- Terminal box¹ Left position
- Standard NEMA MG-1
- Flange Without
- Synchronous speed 3600 rpm
- Output rating 7.5 HP
- Voltage 230/460 V
- Noise level² 72.0 dB(A)
- Mounting F-1
- Rotation¹ Both (CW and CCW)
- Number of poles 2
- Approx. weight³ 139 lb
- Degree of Protection IP55
- Ambient temperature -20°C to +40°C
- Enclosure IC411 - TEFC
- Altitude 1000 m.a.s.l.
- Starting Method Direct On Line
- Duty Cycle Cont.(S1)
- Insulation Class F
- Temperature rise 80 K
- Design B
- Service factor 1.25
- Moment of inertia (J) 0.4879 sq.ft.lb
- Rated torque 11.2 ft.lb
- LRC 7.1x(Code H)
- Locked rotor time 46s (cold) 26s (hot)
- Breakdown torque 350 %
- No load current 5.50/2.75 A
- Locked rotor torque 220 %
- Number of Poles 2
- Slip 2.36 %
- Rated speed 3515 rpm
- L. R. Amperes 123/61.6 A
- Output 7.5 HP (5.5 kW)
- Rated current 17.3/8.67 A
- Rated voltage 230/460 V
- Frequency 60 Hz
- Material (FERT) 50006910
- Frame 215T
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
