.5036OT1BOW56CFL-S WEG AC Motors

Product Details

• Output Rating
  0.5 HP
• Voltage
  115/208-230 V
• Flange Type
  C
• Rated Speed
  3510 rpm
• Number of Poles
  2 Pole
• Synchronous speed
  3600 rpm
• Terminal box¹
  Without Terminal Box
• Flange
  C
• Output rating
  0.5 HP
• Voltage
  115/208-230 V
• Number of poles
  2
• Approx. weight³
  25.2 lb
• Altitude
  1000 m.a.s.l.
• Standard
  NEMA MG-1
• Mounting
  F-1
• Noise level²
  56.0 dB(A)
• Ambient temperature
  -20°C to +40°C
• Rotation¹
  Both (CW and CCW)
• Enclosure
  IC01 - ODP
• Service factor
  1.25 (1.00 @ 208V)
Duty Cycle
Cont.(S1)
Starting Method
Direct On Line
Insulation Class
F
Temperature rise
80 K
Moment of inertia (J)
0.0254 sq.ft.lb
Design
N
Breakdown torque
300 %
Locked rotor time
16s (cold) 9s (hot)
Rated torque
0.748 ft.lb
Locked rotor torque
270 %
LRC
8.8x(Code L)
Frequency
60 Hz
No load current
1.60/0.690-0.800 A
L. R. Amperes
42.2/23.3-21.1 A
Rated speed
3510 rpm
Slip
2.50 %
Number of Poles
2
Rated current
4.80/2.65-2.40 A
Frame
W56C
Rated voltage
115/208-230 V
Output
0.5 HP (0.37 kW)
