721-2103/037-000 WAGO Electrical Connector Accessories

WAGO 721-2103/037-000 2-conductor female connector; Push-in CAGE CLAMP®; 2.5 mm²; Pin spacing 5 mm; 3-pole; 100% protected against mismating; Lateral locking levers; 2,50 mm²; light gray
WAGO

Part#:721-2103/037-000

Manufacturer:WAGO

Product Lifecycle:Active

Get a quick Quote!

2-conductor female connector; Push-in CAGE CLAMP®; 2.5 mm²; Pin spacing 5 mm; 3-pole; 100% protected against mismating; Lateral locking levers; 2,50 mm²; light gray

About the manufacturer: WAGO is one of the manufacturers that offers Electrical Connector Accessories that you can order at Powermatic Associates site. WAGO is the global leader in spring clamp technology for electrical connections and ranks among the top suppliers of components for industrial and building automation. With 28 companies and 9 production facilities employing around 9,000 people worldwide, we ensure expert advice and close customer relationships.

Check out the 721-2103/037-000 WAGO price in the box on the right side or send a quick quote.

Product Details

  • Weight
    8.544002247 g
  • Country Of Origin
    Poland
  • HTS Code
    85366990990

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

721-2103/037-000 Description

WAGO 721-2103/037-000 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 320V and 630V under different conditions, rated impulse voltage of 4kV, and a rated current of 16A. UL and CSA approvals are included, with UL ratings up to 600V and 20A, and CSA ratings up to 300V and 15A depending on the use group. This part features 6 connection points, 3 potentials, and utilizes Push-in CAGE CLAMP technology for connections, supporting solid and fine-stranded conductors of various sizes. It has a 3-pole number, with a pin spacing of 5mm, and dimensions of 31.55mm in width, 20.8mm in height, and 29.8mm in depth. It includes variable coding, anti-rotation protection, and a locking lever for the plug-in connection. The connector is made from light gray Polyamide (PA66), with a flammability class of UL94 V0, and uses a Chrome-Nickel spring steel for the clamping spring and a copper alloy with tin plating for contacts. It operates within a temperature range of -60 to +85°C, has a fire load of 0.159MJ, and weighs 8.5g. This product is RoHS compliant, packaged in boxes of 50 pieces, and has a country of origin of PL.

Manufacturer warranty

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
