232-167 WAGO Electrical Connector Accessories

232-167 on Powermatic Associates
WAGO

Part#:232-167

Manufacturer:WAGO

Product Lifecycle:Active

Get a quick Quote!

THT female header; straight; Pin spacing 5.08 mm; 7-pole; 0.6 x 1.0 mm solder pin; orange

About the manufacturer: WAGO is one of the manufacturers that offers Electrical Connector Accessories that you can order at Powermatic Associates site. WAGO is the global leader in spring clamp technology for electrical connections and ranks among the top suppliers of components for industrial and building automation. With 28 companies and 9 production facilities employing around 9,000 people worldwide, we ensure expert advice and close customer relationships.

Check out the 232-167 WAGO price in the box on the right side or send a quick quote.

Product Details

  • Weight
    6.150001617 g
  • Country Of Origin
    Germany
  • HTS Code
    85366990990
  • Width
    1.459 inches, 37.06 millimeters
  • Weight
    6.150 grams
  • Package Type
    Box
  • Voltage
    300 volts, 320 volts
  • Insulation Material
    Polyamide
  • Height
    0.915 inches, 23.25 millimeters
  • Depth
    0.457 inches, 11.6 millimeters
  • Flammability Class
    V0
  • Current
    12 amperes, 15 amperes
  • Country of Origin
    Germany
  • Contact Type
    Tin
  • Contact Material
    Copper Alloy
  • Connection Type
    For PCB
  • Color
    Orange

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

232-167 Description

WAGO 232-167 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed for PCB applications without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It has electrical ratings per IEC/EN 60664-1 with nominal voltages of 320V (III/3, III/2) and 630V (II/2), rated impulse voltage of 4kV across all categories, and a rated current of 12A. UL and CSA approvals include ratings of 300V and 600V with currents ranging from 10A to 15A depending on the use group. The connector features 7 connection points, a single connection type, and one level, with a pole number of 7. Physical specifications include a pin spacing of 5.08mm, dimensions of 37.06mm in width, 23.25mm in height, and 11.6mm in depth, with a solder pin length of 5mm. It offers variable coding, anti-rotation protection, and is made from orange Polyamide (PA66) with a tin-plated copper alloy for contacts. The connector operates within a temperature range of -60 to +85°C, has a flammability class of UL94 V0, and weighs 6.2g. It is RoHS compliant without exemptions, packaged in boxes of 50 pieces, and has a GTIN of 4044918578745.
