WD-WKCV 4.5T-3/S653 Turck Cordsets

Turck WD-WKCV 4.5T-3/S653 WD-WKCV 4.5T-3/S653 Washdown Cordset, Connection Cordset
Turck

Part#:WD-WKCV 4.5T-3/S653

Manufacturer:Turck

Alt. Part#:U-90430

Product Lifecycle:Active

In-stock parts: 55

Oct 5, 2024

WD-WKCV 4.5T-3/S653 Washdown Cordset, Connection Cordset

About the manufacturer: Turck is one of the manufacturers that offers Cordsets that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.

Check out the WD-WKCV 4.5T-3/S653 Turck price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

WD-WKCV 4.5T-3/S653 Description

Turck WD-WKCV 4.5T-3/S653 is a single-ended mating cable/cordset designed for automation applications. This part features a right-angled 5-pin M12 eurofast female connector with a T-barb fitting and a medium plug body, leading to bare end flying leads. It is constructed with a stainless steel coupling nut and a PVC jacket, ensuring durability and a secure connection. The cable has a length of 3 meters (approximately 9 feet), making it suitable for various installation requirements. It is rated for a current of 4A and a voltage of 250Vac. The sheath of the cable is white, and it falls under the M12 eurofast to bare leads sub-range.

Related documents WD-WKCV 4.5T-3/S653 Specs

WD-WKCV 4.5T-3/S653 777036875 (sheet_1).pdf

This item can ship within 24h!

Manufacturer warranty

$55.20

Stock:

55

Select Qty:

$55.20

$55.20 each
