RU200-CP40-2UN8X2T Turck Industrial Automation Components

RU200-CP40-2UN8X2T on Powermatic Associates
Turck

Part#:RU200-CP40-2UN8X2T

Manufacturer:Turck

Alt. Part#:1610055

Product Lifecycle:Active

Get a quick Quote!

RU200-CP40-2UN8X2T Ultrasonic Sensor, Diffuse Mode Sensor

About the manufacturer: Turck is one of the manufacturers that offers Industrial Automation Components that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.

Check out the RU200-CP40-2UN8X2T Turck price in the box on the right side or send a quick quote.

Product Details

  • Weight
    214 g
  • RoHS
    Yes
  • Country Of Origin
    DEU
  • HTS Code
    8536507000
  • Weight
    214 grams
  • Country of Origin
    Germany
  • Operating Voltage
    15 volts, 30 volts
  • Ambient Temperature
    70 degrees celsius
  • Protection class
    IP40
  • Special features
    Pushbutton
  • Housing material
    Plastic
  • Housing quality
    PBT-GF30-V0
  • Ambient temperature
    0…+70 °C
  • Construction size
    166 x 40 x 40 mm, CP40
  • Electrical connection
    Terminal chamber, Terminal box with cable gland
  • Design
    Rectangular
  • Function
    Proximity
  • Switching element function
    NO/NC
  • Range
    50…2000 mm
  • Operating voltage
    15…30 VDC
  • Output function
    NPN
  • Radiation direction
    straight

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

RU200-CP40-2UN8X2T Description

Ultrasonic Sensor, Diffuse Mode Sensor, Max. range 2000 mm, Separate transducers for transmitter and receiver, Rectangular housing 40 x 40 x 166 mm, Connection via screw terminals, Terminal chamber for M20 x 1.5 cable gland, Teach range adjustable via button, Blind zone: 5 cm, Range: 200 cm, Resolution: 1 mm, Aperture angle of sonic cone: ±60 °, 2 x switching outputs, NPN, NO/NC programmable

Related documents RU200-CP40-2UN8X2T Specs

RU200-CP40-2UN8X2T English-1630965815202.pdf

Manufacturer warranty

$387.20

Request a quote, and we will send availability within minutes.

Select Qty:

$387.20

$387.20 each

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
