RI-43HA6S8-AA2048-12M23/N42 Turck Encoders

Turck RI-43HA6S8-AA2048-12M23/N42 is an incremental rotary encoder designed for flange mounting with a long tether arm. It operates within an ambient air temperature range of -40 to +80°C and features a large-bore through hollow shaft with an isolation insert flange. This encoder is equipped with an optical sensing design and a pre-equipped radial 12-pin M23 Multifast male connector for connectivity. It falls under the Type RI-43 series and has dimensions of H140mm x W135mm x D174mm with a 100mm casing diameter. The encoder is protected to IP65 standards and requires a supply voltage of 10Vdc-30Vdc (12Vdc-24Vdc nom.), with a 300kHz pulse frequency. Constructed from die-cast metal housing, stainless steel shaft, and aluminium flange, it features a 1" hollow shaft bore. Protection functions include short-circuit and reverse polarity protection. It can handle a rotational speed of up to 6000rpm (mechanical limit) and has a moment of inertia of < 220x10^-6kg.m^2. The encoder offers 1 x output (SinCos output; 1Vpp with inverting function; 10Vdc-30Vdc), a resolution of 2048ppr (pulses/revolution), and a current consumption of 65mA (no load).
