QO31001200 Schneider Electric Miniature Circuit Breakers (MCBs)

QO31001200 on Powermatic Associates
Schneider Electric

Part#:QO31001200

Manufacturer:Schneider Electric

Category:Miniature Circuit Breakers (MCBs)

Product Lifecycle:Active

Get a quick Quote!

Square D by Schneider Electric QO31001200 is a Miniature Circuit Breaker (MCB) featuring an auxiliary switch with 1a functionality. It is designed for plug-in mounting and supports a plug-in connection type. This MCB is rated for a current of 100A and can operate at rated voltages of 120V to 240V AC. It accommodates a wire cross-section of 4-2/0AWG for 1 cable Al/Cu. The QO31001200 is a 3 Pole device equipped with 1 Normally Open (NO) auxiliary contact. It has a short circuit breaking rating of 10kA at 240Vac and 5kA at 48Vdc, with box lugs serving as the type of terminals.

About the manufacturer: Schneider Electric is one of the manufacturers that offers Miniature Circuit Breakers (MCBs) that you can order at Powermatic Associates site. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.

Check out the QO31001200 Schneider Electric price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

QO31001200 Description

Square D by Schneider Electric QO31001200 is a Miniature Circuit Breaker (MCB) featuring an auxiliary switch with 1a functionality. It is designed for plug-in mounting and supports a plug-in connection type. This MCB is rated for a current of 100A and can operate at rated voltages of 120V to 240V AC. It accommodates a wire cross-section of 4-2/0AWG for 1 cable Al/Cu. The QO31001200 is a 3 Pole device equipped with 1 Normally Open (NO) auxiliary contact. It has a short circuit breaking rating of 10kA at 240Vac and 5kA at 48Vdc, with box lugs serving as the type of terminals.
