QC816F125S Schneider Electric Electrical Load Centers

QC816F125S on Powermatic Associates
Schneider Electric

Part#:QC816F125S

Manufacturer:Schneider Electric

Category:Electrical Load Centers

Product Lifecycle:Active

Get a quick Quote!

Square D by Schneider Electric QC816F125S is a Combination Service Entrance Device (CSED) designed for surface mounting. It features a ringless meter socket without a bypass, suitable for outdoor use. This device is rated for a current of 125A and supports a single-phase (1PH) network. It offers feed-thru lugs for both line and ground connections. The QC816F125S accommodates 16 single pole circuits or 8 tandem breakers within its dimensions of H1045mm x W477mm x D137mm (H41.16" x W18.76" x D5.41"). It provides 8 spaces and is compatible with wire cross-sections ranging from 6AWG to 350kcmil for aluminium/copper lugs and 8AWG to 2/0AWG for aluminium/copper lugs. Additionally, it has a short circuit breaking rating of 22kA.

About the manufacturer: Schneider Electric is one of the manufacturers that offers Electrical Load Centers that you can order at Powermatic Associates site. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.

Check out the QC816F125S Schneider Electric price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

QC816F125S Description

Square D by Schneider Electric QC816F125S is a Combination Service Entrance Device (CSED) designed for surface mounting. It features a ringless meter socket without a bypass, suitable for outdoor use. This device is rated for a current of 125A and supports a single-phase (1PH) network. It offers feed-thru lugs for both line and ground connections. The QC816F125S accommodates 16 single pole circuits or 8 tandem breakers within its dimensions of H1045mm x W477mm x D137mm (H41.16" x W18.76" x D5.41"). It provides 8 spaces and is compatible with wire cross-sections ranging from 6AWG to 350kcmil for aluminium/copper lugs and 8AWG to 2/0AWG for aluminium/copper lugs. Additionally, it has a short circuit breaking rating of 22kA.
