HMIGTO3510FCW Schneider Electric LCD Touch Panels - HMI Panel

Name: HMIGTO3510FCW
Brand: Schneider Electric

Part#:HMIGTO3510FCW

Manufacturer:Schneider Electric

Category:LCD Touch Panels - HMI Panel

Product Lifecycle:Active

Product description

Schneider Electric HMIGTO3510FCW is a coated operator dialogue touchscreen HMI/Programmable Terminal (PT) featuring 8 function keys and the capability to manage 32 groups of 64 recipes, totaling up to 1024 ingredients. It supports recipe curves, a log alarm log, and includes a built-in real-time clock. For connectivity, it offers a USB mini-B port, a USB type A port, two RJ45 ports, and a 9-pin D-Sub connector. It communicates via Modbus, Modbus TCP/IP, Uni-TE, RS-232C, RS-485, and Ethernet TCP/IP protocols. The device operates on a 24Vdc supply voltage and is designed for flush mounting. It operates within an ambient air temperature range of 0 to +50°C and offers a degree of protection rated at IP65, IP67, and NEMA 4X. The HMIGTO3510FCW has a connection capacity for a 4GB SD card, a memory capacity of 96MB for applications, and a pixel count of 800x480 on a 7" WVGA TFT 65K color display with LED backlight. It is designed to withstand ambient air temperatures for storage between -20 and +60°C. The operating system is Magelis, and the electrical durability of the backlight is rated at 50,000 hours.

Product Details

Integrated Connection Type
COM1 serial link SUB-D 9 RS232C 2400...115200 bps COM2 serial link RJ45 RS485 2400...115200 bps COM2 serial link RJ45 RS485 187.5 kbps Siemens MPI Ethernet RJ45 10BASE-T/100BASE-TX Ethernet RJ45 IEEE 802.3 USB 2.0 type A USB
Local Signalling
Status LED green, steady offline Status LED green, steady operating Status LED orange, flashing software starting up Status LED red, steady power supply (ON) Status LED clear, faded power supply (OFF) COM2 LED yellow, steady data
Character Font
ASCII Japanese (ANK, Kanji) Korean Taiwanese (traditional Chinese) Chinese (simplified Chinese)
Maximum Power Consumption In W
8 W when power is not supplied to external devices 5 W when backlight is OFF 5.5 W when backlight is dimmed 12 W
Brightness
16 levels by touch panel 16 levels by software
Data Storage Equipment
SD card, <= 32 GB SDHC card, <= 32 GB
Downloadable Protocols
Schneider Electric Modicon Modbus Schneider Electric Modicon Uni-TE Schneider Electric Modicon Modbus Plus Schneider Electric Modicon FIPWAY Mitsubishi Melsec third party protocols Omron Sysmac third party protocols Rockwell
Net Weight
2.65 lb(US) (1.2 kg)
Width
8.58 in (218 mm)
Height
6.81 in (173 mm)
Depth
2.36 in (60 mm)
Type Of Cooling
Natural convection
Enclosure Material
PPT
Front Material
PPT
Fixing Mode
by 4 screw clamps
Product Mounting
Flush mounting
Memory Description
Flash EPROM, 96 MB
Data Backed Up
128 kB internal RAM SRAM)
Software Designation
Vijeo Designer configuration software >= V6.1
Inrush Current
30 A

Supply Voltage Limits

19.2…28.8 V

[Us] Rated Supply Voltage

24 V DC

Backlight Lifespan

50000 hours white 77 °F (25 °C)

Touch Panel

Resistive film, 1000000 cycles

Touch Sensitive Zone

1024 x 1024

Display Resolution

800 x 480 pixels WVGA

Display Type

Backlit colour TFT LCD

Terminal Type

Touchscreen display

Range Of Product

Harmony GTO

Display Colour

65536 colours

Product Or Component Type

Advanced touchscreen panel

Supply

External source

Display Size

7 inch

Battery Type

Lithium internal RAM 100 days 5 day(s) 10 year(s)

Control Button Type

8 operation defined using Vijeo Designer push-button key F1...F8

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
