8390318 SAB Servo Motor Cables

8390318 on Powermatic Associates
SAB

Part#:8390318

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SL 839 C -26 AWG/8pr, composite PUR transmission cable with overall tinned copper screen, UL, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Servo Motor Cables that you can order at Powermatic Associates site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 8390318 SAB price in the box on the right side or send a quick quote.

Product Details

  • Color
    Green
  • Weight
    23.59 g
  • Chemical Resistant
    YES
  • Oil Resistant
    Yes
  • UV Resistant
    YES
  • Halogen Free
    YES
  • Submersible
    NO
  • Direct Burial
    NO
  • Movement Type
    Stationary/Flexible
  • Application
    Control, Data, Motor & Drives
  • Gauge
    26 AWG
  • Pair count
    8
  • Number of conductors
    16
  • Cable configuration
    26 AWG/8pr
  • Stranding type
    bare copper, fine strands
  • Insulation type
    Special Polymer
  • Shielded
    Yes
  • Voltage
    30
  • Approvals
    UR AWM, EAC, RoHS
  • RoHS
    YES
  • Temperature range
    -40°C to +80°C
  • Outside diameter (OD)
    0.307 in
  • UOM
    ft
  • CSA Certification
    NO
  • UL Certification
    YES
  • CE Certification
    NO

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

8390318 Description

SAB 8390318 Servo Motor Cable is part of SL 839 C product family, and is designed for Control, Data, Motor & Drives applications. This cable is 26 AWG with 16 conductors, and shielded 26 AWG/8pr cable configuration. Featuring Green color jacket, Special Polymer insulation, and bare copper, fine strands stranding. It has 0.307 in OD, constructed to support Stationary/Flexible movement type, and rated for 30 volts. This Control, Data, Motor & Drives cable can operate in -40°C to +80°C temperature range, it is chemical resistant, oil resistant, UV resistand, Halogen free, and has following approvals: UR AWM, EAC, RoHS. This cable is an excellent choice for Control, Data, Motor & Drives applications.

Related documents 8390318 Specs

8390318 SL_839_C.pdf
