67450734 SAB Halogen Free Cables

SAB 67450734 SABIX SD 745 C FRNC C1 TP - 22 AWG/7pr, shielded halogen-free flame retardant continuous flex data cable, CE, RoHS
SAB

Part#:67450734

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX SD 745 C FRNC C1 TP - 22 AWG/7pr, shielded halogen-free flame retardant continuous flex data cable, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Powermatic Associates site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 67450734 SAB price in the box on the right side or send a quick quote.

Product Details

  • UV Resistant
    YES
  • Cable configuration
    22 AWG (≈ 42/38)/7pr
  • Submersible
    NO
  • Color
    Black
  • Outside diameter (OD)
    0.394 in
  • Weight
    46.93 g
  • Pair count
    7
  • Insulation type
    SABIX
  • Shielded
    Yes
  • Temperature range
    -40°C to +90°C
  • CE Certification
    YES
  • Application
    Control, Data
  • RoHS
    YES
  • CSA Certification
    NO
  • Halogen Free
    YES
  • Gauge
    22 AWG
  • Number of conductors
    14
  • Oil Resistant
    Yes
  • Movement Type
    Continuous Flex
  • Direct Burial
    NO
  • Approvals
    CE, EAC, RoHS
  • UL Certification
    NO
  • Chemical Resistant
    NO
  • Stranding type
    bare copper, extra fine strands
  • Voltage
    500
  • UOM
    ft

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

67450734 Description

SAB 67450734 Halogen Free Cable is part of SABIX® SD 745 C FRNC C1 TP product family, and is designed for Control, Data applications. This cable is 22 AWG with 14 conductors, and shielded 22 AWG (≈ 42/38)/7pr cable configuration. Featuring Black color jacket, SABIX insulation, and bare copper, extra fine strands stranding. It has 0.394 in OD, constructed to support Continuous Flex movement type, and rated for 500 volts. This Control, Data cable can operate in -40°C to +90°C temperature range, it is oil resistant, UV resistand, Halogen free, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Control, Data applications.

Related documents 67450734 Specs

67450734 SABIX_SD_745_FRNC_C1_TP.pdf

Manufacturer warranty
