67052525 SAB Halogen Free Cables

67052525 on Powermatic Associates
SAB

Part#:67052525

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX SD 705 FRNC C1 -24 AWG/25c, halogen-free flame retardant continuous flex data cable, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Powermatic Associates site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 67052525 SAB price in the box on the right side or send a quick quote.

Product Details

  • Color
    Black
  • Weight
    35.83 g
  • Chemical Resistant
    NO
  • Oil Resistant
    Yes
  • UV Resistant
    YES
  • Halogen Free
    YES
  • Submersible
    NO
  • Direct Burial
    NO
  • Movement Type
    Continuous Flex
  • Application
    Control, Data
  • Gauge
    24 AWG
  • Number of conductors
    25
  • Cable configuration
    24 AWG (≈ 32/38)/25c
  • Stranding type
    bare copper, extra fine strands
  • Insulation type
    SABIX
  • Shielded
    No
  • Voltage
    500
  • Approvals
    CE, EAC, RoHS
  • RoHS
    YES
  • Temperature range
    -40°C to +90°C
  • Outside diameter (OD)
    0.343 in
  • UOM
    ft
  • CSA Certification
    NO
  • UL Certification
    NO
  • CE Certification
    YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

67052525 Description

SAB 67052525 Halogen Free Cable is part of SABIX® SD 705 FRNC C1 product family, and is designed for Control, Data applications. This cable is 24 AWG with 25 conductors, and 24 AWG (≈ 32/38)/25c cable configuration. Featuring Black color jacket, SABIX insulation, and bare copper, extra fine strands stranding. It has 0.343 in OD, constructed to support Continuous Flex movement type, and rated for 500 volts. This Control, Data cable can operate in -40°C to +90°C temperature range, it is oil resistant, UV resistand, Halogen free, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Control, Data applications.

Related documents 67052525 Specs

67052525 SABIX_SD_705_FRNC_C1.pdf
