37810225 SAB Multiconductor Cables

37810225 on Powermatic Associates
SAB

Part#:37810225

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABclean SD 787 C TP - 24 AWG/2pr, continuous flex shielded paired data cable, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Multiconductor Cables that you can order at Powermatic Associates site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 37810225 SAB price in the box on the right side or send a quick quote.

Product Details

  • Color
    Black
  • Weight
    13.61 g
  • Chemical Resistant
    NO
  • Oil Resistant
    Yes
  • UV Resistant
    NO
  • Halogen Free
    NO
  • Submersible
    NO
  • Direct Burial
    NO
  • Movement Type
    Continuous Flex
  • Application
    Data
  • Gauge
    24 AWG
  • Pair count
    2
  • Number of conductors
    4
  • Cable configuration
    24 AWG/2pr
  • Stranding type
    tinned copper fine strands
  • Insulation type
    TPE
  • Shielded
    Yes
  • Voltage
    350
  • Approvals
    CE, EAC, RoHS
  • RoHS
    YES
  • Temperature range
    -40°C to +80°C
  • Outside diameter (OD)
    0.217 in
  • UOM
    ft
  • CSA Certification
    NO
  • UL Certification
    NO
  • CE Certification
    YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

37810225 Description

SAB 37810225 Continuous Flex Cable is part of SABclean SD 787 C TP product family, and is designed for Data applications. This cable is 24 AWG with 4 conductors, and shielded 24 AWG/2pr cable configuration. Featuring Black color jacket, TPE insulation, and tinned copper fine strands stranding. It has 0.217 in OD, constructed to support Continuous Flex movement type, and rated for 350 volts. This Data cable can operate in -40°C to +80°C temperature range, it is oil resistant, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Data applications.

Related documents 37810225 Specs

37810225 SABclean_SD_787_C_TP.pdf
