37800303 SAB Multiconductor Cables

Name: 37800303
Brand: SAB

Part#:37800303

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABclean SD 780 C - 22 AWG/3c, continuous flex shielded data cable, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Multiconductor Cables that you can order at Powermatic Associates site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 37800303 SAB price in the box on the right side or send a quick quote.

Product Details

Color
Black
Weight
10.89 g
Chemical Resistant
NO
Oil Resistant
Yes
UV Resistant
NO
Halogen Free
NO
Submersible
NO
Direct Burial
NO
Movement Type
Continuous Flex
Application
Data
Gauge
22 AWG
Number of conductors
3
Cable configuration
22 AWG/3c
Stranding type
bare copper strands, extra fine wires
Shielded
Yes
Voltage
350
Approvals
CE, EAC, RoHS
RoHS
YES
Temperature range
-40°C to +80°C
Outside diameter (OD)
0.197 in

UOM

CSA Certification

UL Certification

CE Certification

YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

37800303 Description

SAB 37800303 Continuous Flex Cable is part of SABclean SD 780 C product family, and is designed for Data applications. This cable is 22 AWG with 3 conductors, and shielded 22 AWG/3c cable configuration. Featuring Black color jacket, and bare copper strands, extra fine wires stranding. It has 0.197 in OD, constructed to support Continuous Flex movement type, and rated for 350 volts. This Data cable can operate in -40°C to +80°C temperature range, it is oil resistant, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Data applications.
