37760461 SAB Multiconductor Cables

Name: 37760461
Brand: SAB

SAB 37760461 SABclean S 776 - 8 AWG/4c, continuous flex control cable, CE, RoHS

Part#:37760461

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABclean S 776 - 8 AWG/4c, continuous flex control cable, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Multiconductor Cables that you can order at Powermatic Associates site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 37760461 SAB price in the box on the right side or send a quick quote.

Product Details

Color
Black
Weight
156.49 g
Chemical Resistant
NO
Oil Resistant
Yes
UV Resistant
NO
Halogen Free
NO
Submersible
NO
Direct Burial
NO
Movement Type
Continuous Flex
Application
Control
Gauge
8 AWG
Number of conductors
4
Cable configuration
8 AWG/4c
Stranding type
bare copper strands, class 6
Insulation type
TPE
Shielded
No
Voltage
500
Approvals
CE, EAC, RoHS
RoHS
YES
Temperature range
-40°C to +80°C

Outside diameter (OD)

0.622 in

UOM

CSA Certification

UL Certification

CE Certification

YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

37760461 Description

SAB 37760461 Continuous Flex Cable is part of SABclean S 776 product family, and is designed for Control applications. This cable is 8 AWG with 4 conductors, and 8 AWG/4c cable configuration. Featuring Black color jacket, TPE insulation, and bare copper strands, class 6 stranding. It has 0.622 in OD, constructed to support Continuous Flex movement type, and rated for 500 volts. This Control cable can operate in -40°C to +80°C temperature range, it is oil resistant, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Control applications.
