35661804 SAB VFD Cables

35661804 on Powermatic Associates
SAB

Part#:35661804

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

VFD XLPE TR Lean - 18 AWG/4c, oil resistant XLPE insulated VFD cable, foil and braid shield, UL, CSA, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers VFD Cables that you can order at Powermatic Associates site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 35661804 SAB price in the box on the right side or send a quick quote.

Product Details

  • Color
    Black
  • Weight
    42.64 g
  • Chemical Resistant
    NO
  • Oil Resistant
    Yes
  • UV Resistant
    YES
  • Halogen Free
    NO
  • Submersible
    NO
  • Direct Burial
    YES
  • Movement Type
    Stationary/Flexible
  • Application
    Motor & Drives
  • Gauge
    18 AWG
  • Number of conductors
    4
  • Cable configuration
    18 AWG/4c
  • Stranding type
    tinned copper strands, class K
  • Insulation type
    XLPE
  • Shielded
    Yes
  • Voltage
    1000
  • Approvals
    UL TC-ER, UL WTTC, c(UL) CIC-TC, CSA AWM, CE, RoHS
  • RoHS
    YES
  • Temperature range
    -40°C to +105°C
  • Outside diameter (OD)
    0.383 in
  • UOM
    ft
  • CSA Certification
    YES
  • UL Certification
    YES
  • CE Certification
    YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

35661804 Description

SAB 35661804 VFD Cable is part of VFD XLPE TR Lean product family, and is designed for Motor & Drives applications. This cable is 18 AWG with 4 conductors, and shielded 18 AWG/4c cable configuration. Featuring Black color jacket, XLPE insulation, and tinned copper strands, class K stranding. It has 0.383 in OD, constructed to support Stationary/Flexible movement type, and rated for 1000 volts. This Motor & Drives cable can operate in -40°C to +105°C temperature range, it is oil resistant, UV resistand, rated for direct burial, and has following approvals: UL TC-ER, UL WTTC, c(UL) CIC-TC, CSA AWM, CE, RoHS. This cable is an excellent choice for Motor & Drives applications.

Related documents 35661804 Specs

35661804 VFD_XLPE_TR_Lean.pdf
