1261604 SAB High Temperature Cables
Part#:1261604
Manufacturer:SAB
Product Lifecycle:Active
Get a quick Quote!
SC 700 C HDTR - 16 AWG/4c, shielded halogen-free high temperature silicone cable, UL, CSA, CE, RoHS
About the manufacturer: SAB is one of the manufacturers that offers High Temperature Cables that you can order at Powermatic Associates site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.
Check out the 1261604 SAB price in the box on the right side or send a quick quote.
Product Details
- Color Black
- Weight 53.52 g
- Chemical Resistant NO
- Oil Resistant No
- UV Resistant NO
- Halogen Free YES
- Submersible NO
- Direct Burial NO
- Movement Type Stationary/Flexible
- Application Control, Power
- Gauge 16 AWG
- Number of conductors 4
- Cable configuration 16 AWG (≈ 27-29/30)/4c
- Stranding type nickel plated copper strands, class 5
- Insulation type Besilen (silicone)
- Shielded Yes
- Voltage 600
- Approvals UR AWM, CE, EAC, RoHS
- RoHS YES
- Temperature range -40°C to +200°C; +250°C (short-term use)
- Outside diameter (OD) 0.425 in
- UOM ft
- CSA Certification NO
- UL Certification YES
- CE Certification YES
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
1261604 Description
SAB 1261604 High Temperature Cable is part of SC 700 C HDTR product family, and is designed for Control, Power applications. This cable is 16 AWG with 4 conductors, and shielded 16 AWG (≈ 27-29/30)/4c cable configuration. Featuring Black color jacket, Besilen (silicone) insulation, and nickel plated copper strands, class 5 stranding. It has 0.425 in OD, constructed to support Stationary/Flexible movement type, and rated for 600 volts. This Control, Power cable can operate in -40°C to +200°C; +250°C (short-term use) temperature range, it is Halogen free, and has following approvals: UR AWM, CE, EAC, RoHS. This cable is an excellent choice for Control, Power applications.
Related documents 1261604 Specs
